<section id="isPasted"><h2>What is BRIDGE Technology?</h2><p>BRIDGE is an architecture framework that combines hardware and software to facilitate the expansion of capabilities and enable seamless communication between the ROV (remotely operated vehicle), its controller, and 3rd party sensors and tools.</p><p>Essentially, it is "bridging" the software controls to the physical ROV, enabling seamless communication and enhanced functionality - hence the name, BRIDGE.</p><p>In today's rapidly evolving tech landscape, the integration of innovative solutions is critical for improving operations across various industries. Deep Trekker has taken its proprietary BRIDGE architecture a step further and developed a groundbreaking advancement with the new BRIDGE.box, transforming the way ROVs are controlled and monitored.</p><p>In this comprehensive guide, we explore the functionalities of BRIDGE technology and its real-world applications in diverse scenarios.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/5tKRaoGRiJ1E9PvfFhUB9Y/d6a238d728b96cf535519d8bda287424/SETUP_full_1__1_.gif" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><p>The expanded technical answer to “What is BRIDGE technology?” is somewhat more complex, much like asking, "What is the internet"?</p><p>It is not simply one easily defined “thing”, but rather, it encompasses many things.</p><p>Let’s break it down a bit further.</p><p>This framework includes hardware, such as BRIDGE.box and custom inputs to communicate between the controller and robots; algorithms that improve functionalities, such as ensuring low latency communication with the robots, allowing for real-time controls with virtually no input lag; and, our BRIDGE.app software application that enhances the operational capabilities of Deep Trekker vehicles.</p></section><section><h2>Key Features of BRIDGE Technology</h2><p id="isPasted"><strong>Responsive Controls</strong>: Advanced algorithms enable near-instant communication between the controller and the vehicle.</p><p><strong>Precise Stabilization</strong>: Ensures reliable camera stability and vehicle station holding in rough water.</p><p><strong>Enhanced Viewing and Recording</strong>: Improved camera and recording capabilities.</p><p><strong>Modular Design</strong>: Supports direct hardware and software integrations with third party equipment and devices.</p><p><strong>Remote Connectivity</strong>: Allows for remote control piloting and remote monitoring.</p><p><strong>Robot Autonomy</strong>: Supports autonomous navigation and station holding, creating an easy and reliable piloting experience.</p></section><section><h3>Adaptability and Customization</h3><p>The adaptable nature of BRIDGE architecture allows it to be tailored to meet the specific requirements of various systems, ensuring compatibility and optimal performance no matter your setup; and, its modular design allows for the integration of other 3rd party hardware and applications, enabling customization based on operational needs.</p><h3>Interoperability and Portability</h3><p>The system's interoperability is another key feature, and supports effective data sharing with other systems, promoting efficient and cohesive operation within a broader technological ecosystem; and, portability ensures it can be easily implemented across different platforms, enhancing flexibility.</p></section><section><h2>What is BRIDGE.box and How Does It Integrate with BRIDGE.app?</h2></section><p>BRIDGE.box is the brain that replaces the traditional Deep Trekker Handheld Controller, allowing you to connect to a Windows device and controller of your choice. BRIDGE.app can then be run from the Windows device, allowing for remote operation of the ROV, real-time monitoring, and multi-monitor setups, along with many additional functions.</p><p>BRIDGE.app can be utilized on Windows devices by connecting it to a BRIDGE.box and plugging it into a Deep Trekker PHOTON, PIVOT, or REVOLUTION ROV.</p><section><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/7sku1NRvqDtSNVVvANvm6R/31bd35c308e7fd3f0d6f0f493ecf4475/unnamed__3_.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><br><p>The integration of BRIDGE.box with Deep Trekker ROVs represents a significant advancement in remote vehicle operation and data management. It enables remote operation from Windows devices and supports real-time monitoring across multiple screens, offering a versatile solution for diverse underwater missions. BRIDGE.box is designed to deliver flexible control options, whether you're operating from a truck, office, laptop, tablet, or console.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/5axEDKUXWCF2PWLoR6FqOq/e8d66b0c2e2c57ff84a7b1002cfc851b/BRIDGE-van-setup.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><br><p>Want to use a gamepad-style controller? No problem. Want six monitors in a shipping container? You got it. Set up your dream office while using a flexible software platform that will grow with your needs.</p><p>For customers who want further customization, such as white labeling capabilities, we can provide your team the tools to take over control of the ROV through your own platforms. Access our API <a href="https://docs.api.deeptrekker.com/index.html" target="_blank">here</a>.</p></section><section><h2>Key Features of BRIDGE.box and BRIDGE.app</h2><ul><li>Remote operation from Windows devices</li><li>Real-time monitoring</li><li>Multi-monitor support</li><li>Enhanced video streaming quality over the Deep Trekker Handheld Controller</li><li>Media playback capability</li><li>Picture-in-picture mode (including auxiliary cameras)</li><li>Increased topside flexibility and comfort</li><li>Support for virtually any controller (yes, even Guitar Hero, technically)</li><li>Compatibility with Windows apps (Screenshare, Viewpoint, etc.)</li></ul><h3>Remote Operation</h3><p>BRIDGE.box allows operators to control Deep Trekker ROVs from any location using a Windows device. This flexibility is particularly beneficial for teams spread across different geographic locations or for those needing to access ROVs in challenging environments.</p><h3>Real-Time Monitoring</h3><p>The framework supports real-time data monitoring on multiple screens, providing a comprehensive view of ongoing missions, enhancing situational awareness, and enabling quick decision-making. With real-time monitoring, you can track the ROVs status, view live video feeds, and access critical data from sensors and other integrated systems simultaneously.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/20Q2LbdJFRyPOLMfFtwW6L/b444c208a2d8206d541368ab37f5932b/IMG_6382-Enhanced-NR.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h3>Higher Quality Images and Video</h3><p>Not only can you enjoy higher resolution displays on multiple monitors, BRIDGE also improves Deep Trekker’s enhanced 4K camera with proprietary image processing algorithms for a premium experience, including auto color correction, image dewarping, improved clarity, upgraded low light performance, and boosted sharpness to enhance your 3D model generation capabilities.</p><h3>Media Playback</h3><p>Record video, take snapshots, and capture vehicle telemetry data into .CSV and .JSON files. Full video and image playback in app, along with file management, enables users to verify recording quality and ensure correctness without having to change devices or programs.</p><h3>Integrated Data Capture</h3><p>Seamlessly capture data from various sources. Integrated data sources such as maps, sonar, and video feeds can be simultaneously displayed with picture-in-picture functionality, enabling more informed decision-making during operations. You also have the ability to drag and drop custom text elements on top of the UI to be captured in recordings, and add auxiliary cameras to the display.</p><h3>Customizable Controls</h3><p>Operators can map input controls on joysticks, keyboards, or gamepads to suit their specific workflow requirements. This customization ensures that users can optimize their control setup for total flexibility and comfort. While we encourage innovation and experimentation, we do advise against using unconventional devices like Guitar Hero controllers. However, the option is there if you feel inclined to explore.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/1PAiqi33GegMSnzJObPLdF/be597a151c2dfd376161e7d69004fbb8/BRIDGE-input-mapping.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h3>Third Party Windows Apps Integration</h3><p>Enables the use of Windows features alongside the app, such as Screen Share for sharing your screen in real-time, and Viewpoint for managing different perspectives or views, as well as compatibility with a wide range of other third-party applications.</p></section><section><h2>Choosing the Right Controller Setup for Your Needs</h2><p>Selecting the optimal controller setup is essential for aligning with your operational needs. Whether you prioritize mobility for rapid deployment or require robust functionality for detailed analysis, making an informed choice will significantly improve your underwater operations.</p><p>By carefully evaluating your specific requirements and considering factors such as portability, control customization, and data integration capabilities, you can maximize the performance and reliability of your underwater ROV. This thoughtful approach will not only boost your operational capabilities but also contribute to overall mission success and safety.</p><h3>Handheld Devices</h3><p>Handheld devices, such as the Deep Trekker tablet (shown below) or specialized controllers, offer portability and ease of use. They are ideal for quick, on-the-go operations but might lack the comprehensive functionality of more permanent setups.</p><p><strong>Benefits:</strong> Highly portable; Touchscreen interface; Quick setup and operation.<br><strong>Challenges:</strong> Limited processing power; Limited by battery life; Smaller screen size.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/9hkqRdNqi5gwLIvgCAvYm/fae92b0805be59436b38500c34d9e4c1/BRIDGE-tablet-setup.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h3>Laptop or Desktop Computers</h3><p>Laptops and office desktops provide a balanced solution, offering more processing power and screen real estate for complex missions. They are suitable for detailed data analysis and long-duration operations.</p><p><strong>Laptops</strong></p><p><strong>Benefits:</strong> Portability with added functionality; Adequate processing power for most missions.<br><strong>Challenges:</strong> Less stable than permanent setups; Battery life limitations.</p><p><strong>Office Desktops<br></strong></p><p><strong>Benefits:</strong> High processing power; Large screen size for detailed monitoring.<br><strong>Challenges:</strong> Limited mobility; Requires a stable power source.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/1lNZdsR6vuDlKn8fjf8Cf2/d2f0ef1f3612b10a1225cd65ccb6efe7/BRIDGE-laptop-setup-5273.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h3>Fixed Topside Console Station and BRIDGE.console</h3><p>For operations requiring continuous and intensive use, permanent console installations are the best option. These setups provide maximum stability and integration capabilities, making them ideal for extensive ship hull inspections or long-term environmental monitoring projects. BRIDGE can be easily integrated into existing control stations without the need to overhaul expensive or complex setups.</p><p>Deep Trekker has also updated their Control Console with a redesigned layout and new features and integrations, making it more robust and practical than ever before. The new BRIDGE.console now comes with a weatherproof case, large screen in lid, integrated keyboard, HDMI, USBs, and ethernet ports, as well as an integrated BRIDGE.box and Direct Power topside box. These integrations mean more functionality and less loose objects and cables during setup, optimizing operations.</p><p><strong>Benefits:</strong> Maximum stability and integration; Ideal for long-term and intensive operations.<br><strong>Challenges:</strong> Lack of mobility; Higher setup and maintenance costs.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/r1xD34vc4QZfKHbQbRKJE/98e5cb5e8c4c19967a389da54b25c90f/BRIDGE-console-setup.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h2>Key Takeaways and Insights</h2><p>BRIDGE.box, integrated with Deep Trekker ROVs, presents a versatile and technically advanced solution for a wide range of underwater missions.</p><p>The platform enables sophisticated customization of controls, allowing for precise adjustments for varying operational scenarios.</p><p>Operators benefit from seamless remote operation capabilities, leveraging advanced protocols for efficient data transmission and real-time monitoring across multiple screens.</p><p>The system's inherent portability enhances its adaptability to diverse environmental conditions, ensuring consistent performance and operational readiness.</p><p>By mastering these features, operators can harness the full potential of BRIDGE technology to achieve optimized mission outcomes with notably improved operational effectiveness.</p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/7Cgma5IryAvu83FjoZBE9m/8914a2bbb11ddb16f98ae1b18fbdf1c3/IMG_6095-Enhanced-NR.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h3>Encouraging Innovation</h3><p>Ultimately, this framework allows different hardware and software to work together easily, empowering developers to incorporate new features, plug-ins, or enhancements without causing things to break. The customizable nature of the system encourages innovation and growth, allowing for future advancements to be implemented without conflict, keeping the framework relevant to current cutting-edge technology.</p></section><section><h2>Custom Solutions for Your Underwater Operations</h2><p>Our experienced team is here to provide expert guidance for a diverse range of applications. Whether you need to inspect vessels, pipelines, underwater assets, or water tanks, or conduct underwater assessments across different industries, we are ready to assist you.</p><p>We ensure tailor-made solutions that precisely match your specific requirements. When you're prepared to acquire your Deep Trekker ROV, don't hesitate to <a href="https://www.deeptrekker.com/contact-us" target="_blank">get in touch</a> with us for a <a href="https://www.deeptrekker.com/request-quote" target="_blank">personalized quote</a>.</p></section>

Operator using custom keyboard controls and laptop to pilot ROV.

Learn about Deep Trekker’s proprietary BRIDGE technology and how it enables you to control your Deep Trekker ROV from any device, and so much more.

BRIDGE Technology: An Architecture Framework Enabling Smarter Control

<section id="isPasted"><h2>Understanding Underwater Navigation</h2><p>In the navigation of underwater environments, knowing your position is critical, yet traditional Global Positioning System (GPS) solutions are rendered ineffective due to the limitations of underwater signal propagation.</p><p>In such challenging conditions, Deep Trekker’s Remotely Operated Vehicles (ROVs), equipped with a suite of advanced sensors and navigation methods, offer a sophisticated alternative.</p><p>Underwater navigation presents unique challenges owing to the attenuation and distortion of signals underwater, necessitating the development of specialized techniques. Deep Trekker ROVs leverage a diverse &amp; robust sensor suite as well as sensor fusion algorithms to navigate in these complex environments. This article examines the complexities of underwater navigation, demonstrating the role of Inertial Measurement Units (IMU), Ultra-Short Baseline (USBL), Doppler Velocity Log (DVL), Dead Reckoning, and other cutting-edge technologies employed by Deep Trekker ROVs.</p></section><section><h2>Key Underwater Navigation Sensors</h2><p>ROVs integrate a comprehensive suite of advanced sensors and methodologies, each playing a crucial role in ensuring reliable underwater navigation. Below is an overview of key sensors</p><p><strong>Camera:</strong> Serving as the primary source of situational awareness, high-definition cameras provide operators with real-time video feeds. They facilitate easy maneuverability during inspections of underwater assets and structures, offering vital visual cues essential for navigation.<img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226099378-1721226099378.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><strong>Inertial Measurement Unit (IMU):</strong> Incorporating a compass, gyroscope, and accelerometer, the IMU tracks the ROV's orientation and motion in three-dimensional space. This data is necessary for stabilizing the vehicle and executing careful maneuvers.</p><p><strong>Pressure Sensor:</strong> Accurate depth measurement capabilities enable ROVs to maintain consistent altitude above the seabed, ensuring safe navigation and inspection operations. The depth / pressure is used to maintain a precise depth below the surface of the water column. The DVL also measures the altitude (vertical distance from the seabed).</p><p><strong>Doppler Velocity Log (DVL):</strong> By measuring changes in sound wave frequencies, DVL systems determine the ROV's speed, direction, and altitude relative to the seabed. This information is vital for maintaining course accuracy and executing dynamic maneuvers.<img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226094348-1721226094348.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"></p><p><strong>Multibeam Imaging Sonar:</strong> Utilizing sound waves for real-time imaging, multibeam sonars offer detailed underwater visibility even in low or zero-visibility environments. They play a crucial role in navigation, object detection, and seabed mapping with exceptional resolution, serving as the primary visual aid when water clarity is compromised.</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226097757-1721226097757.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><p><strong>Ultra-Short Baseline (USBL):</strong> Integration with USBL enhances navigation accuracy and enables autonomous navigation and position holding in challenging underwater conditions.</p><p><strong>Dead Reckoning:</strong> Dead Reckoning is a fundamental navigation method to estimate position based on previously known position, velocity, and heading information. By continuously integrating sensor data and accounting for external factors such as current drift, Dead Reckoning algorithms enable ROVs to maintain correct position estimates over extended mission durations.</p><h2>USBL Integration: Achieving Underwater Navigation Precision</h2><p>The integration of USBL systems transforms underwater navigation, offering exceptional accuracy and reliability. By triangulating the ROV's position relative to surface transducers, USBL technology enables real-time mapping and localization underwater.</p><p>The seamless integration of USBL positioning enhances the capabilities of underwater ROVs, providing users with comprehensive navigation and mapping solutions tailored to diverse underwater applications.</p></section><section><p>USBL triangulation quality is not as accurate compared to GPS triangulation quality; however, the overall quality of USBL is improved through sensor fusion.</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226101337-1721226101337.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><h2>Exploring IMU Technology</h2><p>IMUs are integral components of underwater navigation systems, providing crucial data on an ROV's orientation and motion.</p><p>Let’s take a look at both FOG and MEMS based IMU systems.</p><h3>MEMS vs. FOG IMU: Choosing the Right Technology for Underwater Navigation</h3><p>In the world of underwater navigation, the selection of the appropriate IMU technology plays a crucial role in ensuring accurate positioning and stable control of ROVs. Two prevalent IMU technologies, Microelectromechanical Systems (MEMS) and Fiber Optic Gyroscope (FOG), offer distinct advantages and trade-offs, each suited to specific applications and operational requirements.</p><h3>MEMS IMU: Miniaturization and Cost-Efficiency</h3><p>MEMS IMUs are characterized by their compact size, low power consumption, and cost-effectiveness.</p><p>Leveraging microfabrication techniques, MEMS IMUs integrate miniature sensors, including accelerometers and gyroscopes, onto a single silicon chip. This miniaturization enables MEMS IMUs to be seamlessly integrated into compact ROV designs, offering enhanced maneuverability and operational flexibility.</p><p><a href="https://www.deeptrekker.com/shop/products/sensor-pod" target="_blank"><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226108646-1721226108646.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"></a></p><p>Furthermore, MEMS IMUs boast relatively lower production costs compared to their FOG counterparts, making them an attractive choice for budget-conscious projects and applications requiring mass deployment of underwater vehicles.</p><p>Despite their compact size and cost-effectiveness, MEMS IMUs deliver respectable performance in terms of accuracy and reliability, meeting the demands of many underwater navigation tasks.</p><p>One of the main drawbacks of MEMS is that they are less stable compared to FOG systems. MEMS systems usually rely on a compass to ensure heading stability. This fixes the heading stability issue while maintaining cost-effectiveness, however, this also means that MEMS systems tend to be susceptible to local magnetic distortions.</p><h3>FOG IMU: Precision and Stability at a Higher Cost</h3><p>In contrast, FOG IMUs offer exceptional precision and stability, making them well-suited for demanding underwater navigation applications that require more finite accuracy and long-term reliability. FOG IMUs utilize the principles of interferometry, where light waves traveling through a coiled fiber optic loop experience changes in phase due to rotation, allowing for accurate measurement of angular velocity.</p><p>The inherent stability and accuracy of FOG IMUs make them ideal for tasks such as underwater mapping, seabed surveying, and pipeline inspection, where positioning and motion tracking are critical. However, FOG IMUs typically command higher production costs and exhibit larger physical footprints compared to MEMS counterparts.</p><p>In addition to their cost, it’s important to note that FOG IMUs also require a significant amount of time to boot up and calibrate (approximately 15 minutes). During this time, the vehicle must be completely flat and stationary on solid ground, which makes deployment off of a boat problematic.</p><h3>Choosing the Right IMU for Your Application</h3><p>When selecting between MEMS and FOG IMUs for underwater navigation, it is necessary to consider the specific requirements of the intended application, including accuracy, cost constraints, operational conditions, and deployment scale. For projects prioritizing compactness, cost-efficiency, and versatility, MEMS IMUs offer an attractive solution, providing great performance for a wide range of underwater tasks.</p><p>On the other hand, applications demanding uncompromising precision and long-term stability may favor the superior performance offered by FOG IMUs, despite their higher cost and larger form factor.</p><p>By carefully evaluating the trade-offs between performance, cost, and operational requirements, teams can make informed decisions when selecting the most suitable IMU technology for their underwater navigation needs.</p><p>While MEMS IMUs excel in compactness and cost-efficiency, FOG IMUs offer unmatched precision and stability, catering to the diverse needs of underwater inspections, research, and industrial applications.</p><p>By understanding the strengths and limitations of each IMU technology, stakeholders can make informed decisions to optimize the performance and efficiency of their underwater navigation solutions.</p></section><section><h2>Dead Reckoning Techniques</h2><p>Dead Reckoning serves as a complementary method for underwater navigation, particularly in scenarios where external positioning systems may be unavailable or unreliable.</p><p>By continuously integrating IMU data with velocity and heading information, dead reckoning algorithms estimate the ROV's position based on its previous known location. Deep Trekker ROVs utilize Dead Reckoning techniques to maintain navigation accuracy in sub-sea GPS-denied environments.</p></section><section><h2>ROV Navigation With Sonar</h2><p>With the unique profile of acoustic interpretation, sonar systems can be very valuable when mounted with an ROV. Without sonar, the pilot of the ROV will have to rely on the visual relay of the objects and features through a camera. In low visibility environments, it might be hard to see with the range often being under a meter.</p><p>Sonar systems will drastically increase this range, allowing the pilot to detect objects from much further away. Instead of going over the seabed to find objects, the ROV can remain stationary and scan the entire environment. The pilot can then get an understanding of the area with the man-made objects, natural surfaces, and areas to ignore.</p></section><section><h2>Sensor Fusion: Enhancing Navigation Precision</h2><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226111942-1721226111942.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">The synergy of IMU, DVL, and other sensors through sensor fusion techniques enhances the accuracy and reliability of underwater navigation. By intelligently integrating data streams and compensating for sensor inaccuracies, ROVs achieve navigational precision and stability.<p>Sensor fusion algorithms optimize control responses, mitigate environmental disturbances, and enable autonomous operation, thereby streamlining underwater operations and inspection tasks.</p><p>Through continuous refinement and calibration, sensor fusion elevates the capabilities of Deep Trekker ROVs, ensuring seamless navigation even in dynamic underwater environments.</p></section><section><h2>Advanced Underwater Positioning Systems: A Comparative Analysis</h2><p>The classifications of positioning systems can be divided into three overarching tiers, each catering to specific requirements and budgets.</p><p>High-End Military Grade Solutions: "The high-end, military-grade solutions are typically FOG IMU-based, without the need for DVL integration, employing accelerometers and gyroscopes, albeit at a prohibitive cost," explains Nemanja Kliska, Deep Trekker Team Lead and Autonomy Systems Engineer.</p><p>These top-tier systems, typically priced between half a million to several million dollars, prioritize uncompromising accuracy and reliability. Utilizing FOG IMU-based technology, these systems, commonly found on military vessels and submarines, employ gyroscopes and accelerometers to achieve precise navigation without reliance on external sensors like DVL.</p><p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1721226111248-1721226111248.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"></p><p>AC Spark Plug Titan Inertial Measurement Unit</p><p><br></p><p><strong>High-End Civilian Systems:</strong> Positioned below military-grade solutions, high-end civilian systems offer advanced navigation capabilities at a relatively lower cost. Incorporating IMU or AHRS technology - comprising accelerometers, gyroscopes, and magnetometers - these systems ensure robust performance in various underwater environments. Moreover, some variants employ FOG systems to mitigate heading drift, enhancing positional accuracy.</p><p><strong>MEMS-based Systems:</strong> Representing the next tier, MEMS-based systems provide a cost-effective alternative with acceptable performance metrics. Integrating MEMS gyroscopes and accelerometers, these systems offer satisfactory accuracy under optimal conditions. However, they rely heavily on compass or magnetometer data and require continuous calibration to mitigate errors and environmental interference, and require the incorporation of DVL systems.</p></section><section><h2>Advancing Underwater Navigation with Deep Trekker ROVs</h2><p>In conclusion, the utilization of advanced sensors and positioning methods transforms underwater navigation with Deep Trekker ROVs. Through the integration of IMU, DVL, USBL, and other cutting-edge technologies such as Dead Reckoning, Deep Trekker ROVs offer groundbreaking precision and reliability in navigating challenging underwater environments.</p><p>With our commitment to advancing underwater technology, Deep Trekker remains at the forefront, providing innovative solutions for underwater inspections and research, continuing to redefine the possibilities of underwater navigation, and paving the way for future discoveries and advancements in marine industries.</p><p>Our experienced team is at your service to offer expert guidance for a wide spectrum of applications, ranging from inspecting hull vessels to water tanks to conducting underwater assessments across various industries. We ensure tailor-made solutions that precisely match your specific requirements. When you're prepared to acquire your Deep Trekker ROV, don't hesitate to <a href="https://www.deeptrekker.com/contact-us" target="_blank">get in touch</a> with us for a <a href="https://www.deeptrekker.com/request-quote" target="_blank">personalized quote.</a></p></section>

Explore advanced underwater navigation tech with Deep Trekker ROVs. Learn about MEMS and FOG IMU, Dead Reckoning, and USBL integration for precise positioning.

MEMS vs FOG IMUs: Exploring Underwater Navigation Technology

<section id="isPasted"><h2>What is Dead Reckoning?</h2><p>Dead Reckoning navigation, also known as "deduced reckoning," relies on the principle of estimating the current position based on the last known position, velocity, and heading. It involves using the direction and speed of movement to calculate where you are now relative to where you were previously.</p><p>Dead Reckoning is particularly useful in scenarios where GPS signals are unreliable or unavailable, such as underwater environments where GPS signals cannot penetrate. This method has been integral to navigation, serving as a reliable means of orientation when other references are unavailable or unreliable.</p><p>“Dead reckoning is quickly becoming our new favorite way to operate ROVs and understand positioning of our vehicles,” says Sam Macdonald, President of Deep Trekker. “Setting up USBL or flying completely blind is hard for us as users and our customers. We want to make the piloting experience as easy as possible.”</p><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzIwMDI0OTgxMTkzLTE3MjAwMjQ5ODExOTMucG5nIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"></section><section><h2>The Significance of Dead Reckoning in Underwater Navigation?</h2><p>There are numerous challenges with underwater navigation. Unlike terrestrial or aerial navigation, where landmarks or satellites provide reference points, underwater environments offer minimal visual cues.</p><p>Factors such as fluctuating ocean currents, variations in water density, and unpredictable underwater terrain further complicate the navigation challenges. Without reliable navigation, underwater vehicles run the risk of veering off course, potentially endangering both the vehicle itself and any onboard equipment or personnel.</p><p>Navigating underwater environments poses distinct challenges, requiring specialized techniques like Dead Reckoning to ensure safe and efficient operations. Underwater navigation lacks prominent landmarks or GPS signals, making reliance on Dead Reckoning a key method for accurate positioning.</p><p>This method, reminiscent of long-standing historical navigation practices, becomes particularly important in underwater operations where traditional navigation aids like landmarks or celestial bodies are inaccessible.</p><p>Understanding and implementing Dead Reckoning involves leveraging advanced sensors and algorithms to mitigate inherent challenges, such as sensor inaccuracies and cumulative drift. As technology progresses, optimizing Dead Reckoning capabilities becomes pivotal for enhancing underwater navigation.</p><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzIwMDI0OTgwNjMzLTE3MjAwMjQ5ODA2MzMucG5nIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><p>Deep Trekker’s PIVOT and REVOLUTION ROVs can operate with Dead Reckoning utilizing an upgraded inertial measurement unit (IMU) and Doppler Velocity Log (DVL) sensor combined with our BRIDGE software. The goal of these ROV systems is to simplify the experience so customers can input an initial position and then get in the water and go. That doesn’t mean there aren’t any best practices you can leverage to optimize your experience! Below are some tips and tricks to assist with your ROV piloting.</p><h3>The 6 Rules of Dead Reckoning</h3><p>The <a href="https://www.usna.edu/Sailing/_files/documents/2019_OSTS_Documents/Navigation_101_05MAR19.pdf" target="_blank" data-lf-fd-inspected-kn9eq4roawkarlvp="true">"6 Rules of Dead Reckoning"</a> are guidelines used in navigation, particularly in maritime and aviation contexts, to ensure that an estimated position (Dead Reckoning position) remains as accurate as possible throughout a journey. These rules help navigators keep track of their position and make necessary adjustments. To effectively maintain the vessel’s Dead Reckoning position, the navigator should follow theses 6 rules:</p><p><strong>1. Regular Position Updates:</strong> Update the Dead Reckoning position at regular intervals, typically every hour on the hour. This helps account for changes in speed, course, and environmental conditions that may affect the estimated position. This periodic recalibration is essential for compensating for sensor drift, especially prevalent in underwater technology. Manual recalibration or resurfacing with GPS helps in correcting any deviations and maintaining accuracy.</p><p><strong>2. Adjustment after course changes:</strong> Following any alteration in the vehicle's course, promptly update the Dead Reckoning position to accommodate the modified trajectory. Utilize additional sensors such as a Doppler Velocity Log (DVL) sensor that tracks changes from the seafloor for underwater vehicles or Inertial Measurement Unit (IMU) sensors that track vehicle orientation changes to ensure alignment with the intended route.</p><p><strong>3. Adjustment after speed changes:</strong> Whenever there is a change in the vehicle's speed, it's also important to update the Dead Reckoning position immediately to help ensure that the calculated position remains accurate, considering the altered velocity.</p><p><strong>4. After every fix or running fix:</strong> A "fix" is a position obtained from external references, such as celestial observations, GPS, or terrestrial landmarks. A "running fix" is an ongoing series of fixes that helps refine the Dead Reckoning position. After obtaining either a fix or running fix, the navigator should update the Dead Reckoning position to incorporate this more accurate position information. In the case of an ROV, running fixes could be a GPS mounted on top that gets a fix whenever surfacing or a USBL getting pings during its dive. A fix also could be from a manual GPS input by the user when the ROV surfaces.</p><p><strong>5. After plotting a single line of position:</strong> A line of position is a navigational line that represents the possible positions of a vehicle at a specific time. It is determined using observations of celestial bodies, radar ranges, or other means. After plotting a single line of position, the navigator should update the Dead Reckoning position to account for this new piece of positional data.</p><p><strong>6. DR twice and label with Course and Speed:</strong> After every fix or running fix (repeated for emphasis). Reiterating the importance of updating the Dead Reckoning position after obtaining a fix or running fix. This ensures that the Dead Reckoning position continuously incorporates the most accurate position information available.</p><p><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzIwMDI0OTgxMDk5LTE3MjAwMjQ5ODEwOTkucG5nIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"></p><p>Fig. 1: Example of a Mercator chart style Universal Plotting Sheet used by the Navy for navigation.</p></section><section><h2>Integration of Dead Reckoning with Other Navigation Techniques</h2><p>While Dead Reckoning serves as a foundational navigation method and can be a standalone tracking method, its effectiveness can be amplified through integration with complementary techniques. By combining Dead Reckoning with other navigation methods, such as acoustic positioning systems and satellite-based navigation, navigators can enhance positional accuracy and resilience to environmental challenges.</p><p>Acoustic positioning systems, such as Ultra-Short Baseline (USBL), Short Baseline (SBL), and Long Baseline (LBL), provide precise localization capabilities by measuring the time of flight of acoustic signals between transponders and the vehicle. By incorporating acoustic position updates into Dead Reckoning calculations, navigators can refine their estimated positions and mitigate drift accumulation.</p><p>Similarly, satellite-based navigation systems, including GPS and GNSS (Global Navigation Satellite System), offer helpful external references for validating Dead Reckoning positions. While traditional GPS signals may be unavailable underwater, emerging technologies such as underwater GPS and Differential GNSS (DGNSS) enable precise positioning in submerged environments. By cross-referencing Dead Reckoning positions with satellite-derived fixes, navigators can ensure greater accuracy and reliability in their navigational estimates.</p><p>Furthermore, fusion algorithms, such as Deep Trekker’s Sensor Fusion algorithms, that integrate data from multiple sensors and navigation methods can optimize positional accuracy and robustness. By leveraging the strengths of each technique while compensating for their respective limitations, fusion algorithms provide a comprehensive solution for underwater navigation challenges.</p></section><section><h2>The Role of Sensors in Dead Reckoning</h2><p>Sensors play a significant role in Dead Reckoning by providing essential data inputs for calculating position estimates. Particularly in underwater navigation scenarios with ROVs, characterized by limited visual references, sensors serve as the eyes and ears of the vehicle, capturing crucial information about its movement and surroundings.</p><p>Various types of sensors are employed to track different aspects of the vehicle's motion. Doppler Velocity Log (DVL) sensors measure the vehicle's velocity relative to the seafloor by analyzing Doppler shifts in acoustic signals. This data is integral for calculating speed and direction changes, forming the basis of Dead Reckoning calculations. Additionally, Inertial Measurement Unit (IMU) sensors track the vehicle's orientation and angular velocity, providing necessary inputs for maintaining course accuracy.</p><p>Advancements in sensor technology, such as miniaturization and improved accuracy, have also enabled more sophisticated Dead Reckoning systems. MEMS (Micro-Electro-Mechanical Systems) sensors, characterized by their compact size and low power consumption, have become increasingly prevalent, offering a perfect blend of performance and efficiency for underwater navigation applications.</p><p>By leveraging the capabilities of these sensors, Dead Reckoning systems can navigate with improved precision, overcoming the challenges posed by the underwater environment and enabling safer and more efficient navigation.</p></section><section><h2>Understanding the Limitations of Dead Reckoning</h2><p>While Dead Reckoning serves as a valuable navigation technique, it is not without its challenges and limitations. Understanding these factors is important for mitigating risks and optimizing the performance of Dead Reckoning systems.</p><p>One notable challenge is the accumulation of errors over time, often referred to as "dead reckoning drift". This drift can arise from sensor inaccuracies, environmental disturbances, and uncertainties in the vehicle's dynamics. It’s important to note that these errors can compound, leading to considerable deviations from the true position, which is why periodic updates and recalibrations are so critical for maintaining accurate positional data.</p><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzIwMDI0OTgxMTM4LTE3MjAwMjQ5ODExMzgucG5nIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii"><p>Dead Reckoning is also susceptible to disruptions caused by external factors such as ocean currents, water density variations, and submerged obstacles. These dynamic environmental conditions can impede the vehicle's trajectory, making it challenging to maintain accurate position estimates.</p><p>Additionally, reliance solely on Dead Reckoning in scenarios with limited external references, amplifies the risk of navigation errors. In such cases, a single miscalculation or sensor malfunction could lead to navigation errors with potentially serious consequences.</p><p>Addressing these challenges requires a multi-faceted approach, combining robust sensor technologies, advanced algorithms, and strategic operational practices. By continually refining Dead Reckoning systems and incorporating complementary navigation techniques, such as Deep Trekker’s Sensor Fusion algorithms, operators can navigate with greater confidence and reliability in challenging underwater environments.</p></section><section><h2>Dead Reckoning Empowering ROV Operations</h2><p>Dead Reckoning is a fundamental navigation technique, offering a practical solution for navigating the intricate and often unpredictable underwater terrains encountered by ROVs (remotely operated vehicles) used for underwater operations.</p></section><section><p>By leveraging known parameters and updating positions in responses to changes in course and speed, Dead Reckoning provides a practical means of estimating positions where traditional navigation aids may be unavailable or impractical.</p><p>Its integration with complementary technologies such as acoustic positioning systems enhances its accuracy and robustness, making it a valuable tool for underwater operations and inspection tasks.</p><p>As advancements in sensor technology and navigation algorithms continue, Dead Reckoning holds promise as a dependable navigation technique for conducting essential vessel inspections with improved precision and efficiency, even in challenging underwater environments.&nbsp;</p><p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1720025957910-IMG_6444.png" style="width: 100%px;" class="fr-fic fr-dib"></p></section><section><h2>The Deep Trekker Advantage</h2><p>Deep Trekker ROVs, engineered with rugged industrial-grade materials, are designed for versatility and durability. They offer immediate deployment and a comprehensive variety of advanced features. These ROVs are highly portable and quick to set up, featuring powerful LED lighting, a live 4K video feed, and up to 360-degree field of view, imaging sonar, and flexible sampling tools.</p><p>Our experienced team is at your service to offer expert guidance for a wide spectrum of applications, ranging from inspecting hull vessels to water tanks to conducting underwater assessments across various industries. We ensure tailor-made solutions that precisely match your specific requirements. When you're prepared to acquire your Deep Trekker ROV, don't hesitate to <a href="https://www.deeptrekker.com/contact-us" target="_blank">get in touch</a> with us for a <a href="https://www.deeptrekker.com/request-quote" target="_blank">personalized quote.</a></p></section>

DEep Trekker REVOLUTION ROV with SensorPod+ Sensor Fusion

Everything you need to know about Dead Reckoning for underwater navigation.

Dead Reckoning 101: Everything You Need to Know

Drones are integral to military operations globally, especially in high-risk environments where manned flight is impractical. Learn how to integrate sensors into these devices properly.

Drone PCBAs: Tackling Sensor Integration for Defense & Beyond

<p id="isPasted">InDro Robotics – as always – has been hard at work on innovative new products. And we’re particularly proud of our latest accomplishment: The InDro Controller.</p><p>It’s an all-in-one solution for operating virtually any type of robot from a highly secure console. It’s completely robot-agnostic, very easy to use – and exceedingly powerful. We’ll get into the details as we go, but first let’s hear from Front End Developer RJ Bundy with an elevator pitch.</p><p>“It’s an all-in-one data visualization, robot management and robot control software,” he says. “Whether&nbsp;you’re a student first learning how to use a robot or you’re a commercial giant, you’d be able to manage and maintain all of your robots.”</p><p>He’s not exaggerating. We walked through a demo of this system recently, with Head of R&amp;D Sales Luke Corbeth at the controls and Bundy explaining the various features. We connected remotely with one of our InDro robots. The software immediately detected all of the sensors on the platform, offering up a display of windows showing the data they were collecting with minimal latency.</p><p>“It can handle all sorts of data,” says Bundy. “It doesn’t matter if the robot has standard or custom sensors, InDro Controller can automatically detect and visualize them. For example, if you added a radar unit to an existing robot, the system will pick up on that immediately.”</p><p>Of course, it has teleoperation. Missions can be run manually or autonomously (with InDro’s autonomy stack loaded onto any ROS-based robot).</p><p>“We have a GPS-based autonomy – which is better for outdoors – and then we have a SLAM- (Simultaneous Localisation and Mapping) based autonomy which is ideal for indoors,” says Corbeth.</p><p>And while InDro Controller has very complex capabilities, it’s a snap to use.</p><p>“Once it’s set up, it’s pretty straightforward to initiate the mission. Even someone without any robotics knowledge could do it,” he adds.</p><p><em>Below: The Pilot View mode in InDro Controller. Data from any desired sensors is displayed with minimal latency via a highly secure connection.</em><em><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzE4MjkyNzQ3Mzk1LVBpbG90LVZpZXcucG5nIGNvcHkuanBnIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" style="width: 100%px;" class="fr-fic fr-dib" alt="Teleoperation Pilot View"></em></p><h3 id="isPasted">Highly Secure</h3><p>Regardless of whether you’re a startup, researcher, or a major corporation collecting sensitive data – security is important.&nbsp;InDro Controller has been built with that in mind.</p><p>“We’ve created an interface that makes it very hard for a third party to intercept any of those commands or the data coming from the robot to you.”</p><p>Though the person controlling the robot is the primary login, others with a secure login can also monitor the missions remotely from anywhere in the world. The software can store as many repeatable missions as you can throw at it, and you can initiate a previously stored mission with a single click.</p><h3><br></h3><h3>Mission Planning</h3><p>Mission planning could not be simpler.</p><p>For the first mission, the pilot would manually control the robot. InDro Controller uses an Xbox controller plugged into your computer for intuitive operation (though other options are available). All buttons on the Xbox device can be quickly mapped to carry out specific functions.</p><p>InDro Controller tracks everything you’ve done – and we mean everything – and saves it as a repeatable autonomous mission.</p><p>“If you manually drive the robot somewhere, it will remember it’s been there and it’ll be able to go back, follow that same path every time. It will also remember to carry out any specific actions you’ve taken at those points of interest, including camera angles, zoom, etc.” says Bundy.</p><p>The mission planner also automatically loads a map to locate your robot (you also have the option of satellite view), so you can monitor exactly where it is on any given mission.</p><p>And, of course, it can do this for an entire fleet of robots.</p><p><em>Below: InDro Controller shows Points of Interest – which can be repeated with saved missions</em><em><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzE4MjkyODA1NzE1LUF1dG9ub215LUdob3N0cy5wbmcgY29weS5qcGciLCJlZGl0cyI6eyJyZXNpemUiOnsid2lkdGgiOjk1MCwiZml0IjoiY292ZXIifX19" style="width: 100%px;" class="fr-fic fr-dib"></em><br></p><h3 id="isPasted">Highly Customizable</h3><p>InDro Controller has been designed to allow users to easily customize the user interface for any robot, any mission, and any dashboard view. Multiple streams of data, including upload and download speeds, battery levels and overall robot health are available at a glance. Oh, and did we mention it also works with third-party autonomy stacks?</p><p>“The dashboard, the cameras, the heads up display on the autonomous missions – those all can be customized,” says Bundy. “We’re also adding other personal user customizations, like a light and dark mode, metric conversion, schedule missions – all the kinds of features you could want.”</p><p>InDro Controller already works exceptionally well. But – as with all of our R&amp;D projects – it will continually be refined with additional features and functionality.</p><p>“We’re heavily invested in continuously improving the software,” says Corbeth. “So regardless of which version you’re shipped, know that this is something that InDro Robotics is constantly developing and improving with client feedback in mind to ultimately provide the best mission planning, teleoperations and development software tool in the robotics industry.”</p><p>Speaking of versions, there’s a simpler version of InDro Controller – which does not have the autonomy features – already being used for missions in the academic world. Feedback has been excellent.</p><p>“Users tell us they find InDro Controller Lite exceedingly powerful, but also very simple to use. That was exactly our goal in developing this product,” says Corbeth.</p><p><span dir="ltr">Academics and corporate innovation groups could take advantage of the Lite version, while the Industrial package is intended for solving more complex problems in an industrial environment.</span></p><p>&nbsp;</p><h3>Satisfying R&amp;D</h3><p>For Front End Developer Bundy, who oversaw this project with support from other engineering staff, it’s been a hugely satisfying – and challenging – project.</p><p>“A lot of the customization features were pretty difficult because it has to be robust and dynamic, which is always tough,” he says. “This is a relatively complicated application and I’ve managed to put together something pretty nice and functional – and it will only get better. “I’ve had a bunch of other help, but putting together the UI for InDro Controller has been, and continues to be, highly satisfying.”</p><p><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzE4MjkyOTIxNTg4LUFkbWluLnBuZyBjb3B5LmpwZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 100%px;" class="fr-fic fr-dib"></p><h3 id="isPasted">InDro's Take</h3><p>We’re obviously excited about InDro Controller. And we’re particularly excited because we have a forthcoming piece of hardware – the InDro Module. It’s a small box with a lot of brains that can be added to any robot to increase functionality and enable the seamless addition of sensors and other modifications (as well as pre-loaded autonomy stack and ROS drivers). We’ll have more on that soon, but it’s the perfect match for InDro Controller for users with complex requirements.</p><p>For the moment, we’re looking forward to putting both the Lite and Industrial versions into the hands of clients.</p><p>“When we first began remote teleoperation several years ago, we relied on third-party software as the UI,” says InDro Robotics CEO Philip Reece. “But we found it wasn’t powerful or customizable enough for our needs. It also required that we have our own autonomy stack – and we did – but many clients do not. InDro Controller comes with our proprietary autonomy stacks for both outdoor and GPS-denied locations. And, as noted previously, this is a long-term project, where even early adopters can be assured the package will be continuously refined with additional features.”</p><p>Word has already been spreading in the R&amp;D and commercial fields about this product, and the feedback from those using the Lite version has been outstanding. Interested in learning more or seeing a demo? Contact Luke Corbeth <a href="https://indrorobotics.ca/connectwithanexpert/" target="_blank">here</a>.</p>

An all-in-one solution for operating virtually any type of robot from a highly secure console.

InDro Controller: A Simple Solution to Complex Robotics Missions

<section id="isPasted"><p>Clean, readily available water is absolutely imperative for our health and well-being. A massive part of water maintenance is the regular cleaning of storage tanks. Over time, sediment from particles and minerals in the water sink to the bottom of the tank, eventually creating a layer of sediment or sludge which can impact both the quality of the water and the structural integrity of the tank.</p><h2>Understanding Standpipe Water Tower</h2><p>Standpipe water towers typically represent the most straightforward approach to elevated water storage when dealing with lower capacities. These ground-supported structures closely resemble upright pipes, aligning with their namesake.<img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/R2MqI7R1Qd6zr0gIcJ37b/14a9ea400b65fa97c083cbd6a25f7c2f/unnamed.jpg" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">This straightforward design offers the advantages of a modest initial expense and a space-efficient solution for housing significant water quantities. However, the standpipe design does present its share of challenges.</p><p>Given the substantial surface area relative to volume, standpipe water towers face challenges related to weather-induced fluctuations in water temperature, impacting water quality and causing thermal stratification issues.</p></section><section><p>Learn about the different types of industrial water tanks and how preventive maintenance reduces the tank's deterioration over time.</p><a href="https://www.deeptrekker.com/news/water-tank-cleaning-robot" target="_blank" rel="">WHY IS IT IMPORTANT TO INSPECT WATER TANKS</a></section><section><h3>Benefits of a Standpipe Water Tank</h3><h3>Cost-Effective</h3><p>The additional elevation of the standpipe tank enables it to harness gravity's force to sustain adequate water pressure, facilitating the effective distribution of water stored within its reserves. The gravity-driven pressure system eliminates the necessity for a pumping mechanism, resulting in significant cost savings and positioning standpipes as one of the most cost-effective storage tank alternatives available.</p><h3>Customizable</h3><p>Standpipe tanks offer a high degree of customization, allowing you to tailor the tank's height to meet seismic, diameter, and loading requirements.</p><h3>Stable and Secure</h3><p>Standpipe tanks are typically constructed from factory-coated epoxy and glass-fused bolted steel materials, ensuring their long-lasting durability. Unlike lower-quality tanks that may require frequent replacement, these tanks are designed to stand the test of time.</p><p>Their robust construction virtually eliminates the risk of leakage and significantly reduces the likelihood of damage. Furthermore, the bolted steel construction provides effective protection against thermal stratification, a common issue in standpipe tanks due to their increased height, which exposes them to more sunlight and, consequently, heat. Standpipe tanks are among our most dependable and resilient designs.</p></section><section><h2>Ensuring Water Quality: The Importance of Standpipe Water Tank Cleaning</h2><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/5QIged8xUPu7Q7zZV23HTm/f5e05980fc3de1ed8e6c440f1e86dd67/Outlet_cleaning__2_.jpg" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">Cleaning standpipe water tanks is essential to maintain water quality and ensure the safety of stored water. Over time, sediment, debris, and contaminants can accumulate inside the tank, leading to potential health risks and water quality deterioration.<p>Regular cleaning helps prevent issues like bacterial growth, algae formation, and the buildup of sludge, all of which can compromise the purity and safety of the water supply.</p><p>Regular cleaning of standpipe water tanks is crucial for maintaining water quality and ensuring the safety of stored water. Discover why this practice is essential for health and longevity.</p><h3>Preventing Microbial Growth: A Health Imperative</h3><p>Standpipe water tanks, if not cleaned regularly, become breeding grounds for harmful microorganisms like bacteria, algae, and fungi. Learn how routine cleaning inhibits microbial growth, preventing health risks associated with waterborne diseases such as typhoid, legionella, and malaria. Routine cleaning and disinfection inhibits the growth of these microorganisms, ensuring that microbes are reduced and the formation of biofilms caused by stagnant water is prevented, and the water remains safe for consumption.</p><p>The World Bank estimates that approximately 1.8 million people die each year from diarrheal diseases linked to unsafe water and poor sanitation. Regular tank cleaning can help reduce the risk of waterborne diseases by ensuring clean and safe drinking water.</p><h3>Extending Tank Longevity</h3><p>The&nbsp;<a href="https://www.awwa.org/" target="_blank">American Water Works Association (AWWA)&nbsp;</a>notes that the accumulation of sediments and corrosive elements can result in costly repairs and premature tank replacement.</p><p>The buildup of sediment, debris, and corrosive agents inside the tank can result in structural degradation and corrosion. Failing to conduct proper cleaning procedures can substantially diminish the tank's longevity, potentially necessitating expensive repairs or early replacement. Consistent and thorough cleaning plays a pivotal role in safeguarding the tank's structural integrity, ultimately prolonging its effective operational lifespan.</p><h3>Ensuring Regulatory Compliance</h3><p>Maintaining water quality is vital to meeting health and safety standards. Unclean tanks can compromise water quality, leading to potential violations of regulatory guidelines. Regular cleaning helps ensure that water quality is consistently within acceptable limits, reducing the risk of non-compliance and associated penalties.</p><p>Various regulatory bodies, such as state and federal agencies, have guidelines and regulations for water quality and tank maintenance. Non-compliance can result in fines and penalties.</p><h3>Detecting and Preventing Damage</h3><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/2XZ6QMUbMnWi1I2apZRh5l/a6f8f99a37880dcecb2d6c231bcde357/zsolt-palatinus-pEK3AbP8wa4-unsplash.jpg" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">During the cleaning process, inspectors can identify potential issues such as leaks, cracks, or material deterioration. Timely detection of damage allows for prompt repairs, preventing more extensive and costly problems down the road. This proactive approach helps safeguard the overall functionality of the tank.<p>Sediment and debris in a water tank can also displace a significant volume of water, leading to water loss. According to the&nbsp;<a href="https://www.epa.gov/home" target="_blank">U.S. Environmental Protection Agency (EPA)</a>, water loss due to sediment buildup can be as high as 20% of the tank's capacity.</p></section><section><h2>Cleaning Standpipe Water Tanks: Exploring Effective Methods</h2><p>Various methods are employed to effectively remove sediment, contaminants, and debris that can accumulate inside these tanks over time. From manual cleaning procedures to advanced technologies like remotely operated vehicles (ROVs), each method serves the vital purpose of preserving the safety and reliability of the water supply system. In this section, we will explore some of these methods used for cleaning standpipe water tanks and their respective advantages and applications.</p><h3>Manual Cleaning: A Traditional Approach for Smaller Tanks</h3><p>Manual cleaning is one of the traditional methods used for cleaning standpipe water tanks, particularly in smaller tanks where access is relatively straightforward. Trained personnel enter the tank and physically remove sediment, debris, and contaminants. This method often involves the use of tools like shovels, brushes, and squeegees. While effective for small tanks, it can be labor-intensive and time-consuming.</p><p>The process involves draining the tank, entering and inspecting, scrubbing and cleaning with tools, disinfection, and finally, inspection and repair.</p><h3>Advantages:</h3><p>Suitable for smaller standpipe tanks with straightforward access. Allows for a detailed visual inspection of the tank's interior. Can be cost-effective for smaller tanks.</p><h3>Challenges and Limitations:</h3><p>Labor-Intensive: Manual cleaning can be physically demanding and time-consuming, especially for larger tanks. Limited practicality for larger tanks: It is less practical for larger or deeper tanks where entry is more challenging. Water Disposal challenges: Handling and disposing of the water drained from the tank can be logistically challenging and wasteful. Safety Concerns: Workers must adhere to strict safety protocols when entering confined spaces and handling cleaning materials. Surfaces may be slippery due to sediment or cleaning agents. Risk of contracting waterborne diseases and contamination, in a confined space in the presence of hazardous chemicals. Limited Reach in Complex Designs: Manual cleaning may not effectively reach all areas, especially in complex tank designs.</p><h3>Diver Cleaning</h3><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/1ooByIv9M0juoZQMPmZ8Pu/fa97d784e47d19821ad8a15c4b7afea3/diver-ge1df722b6_1280.jpg" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">In larger tanks with deeper water levels, professional certified divers may be employed to enter the water tank and perform cleaning and inspection tasks underwater. Divers equipped with specialized cleaning equipment and underwater tools can effectively clean and inspect the tank's interior. This method is particularly suited for larger tanks where human entry is necessary due to depth, access restrictions, or complex structural features.<h3>Advantages:</h3><ul><li>Suitable for larger standpipe tanks with challenging access or deep water levels.</li><li>Allows for a thorough visual inspection of the tank's interior.</li><li>Effective in removing sediments and biofilms that may not be reached by other methods.</li></ul><h3>Challenges and Limitations:</h3><p>Costly: Diver cleaning can be expensive due to the specialized training, insurance, and equipment required. Limited to Depth: Diver cleaning is primarily used for tanks with sufficient water depth to require human entry. Safety Risks: Diver safety is of utmost concern, and stringent safety protocols must be followed. As well as the risk of being submerged in a confined space, there also may be low visibility which makes it dangerous and difficult to assess areas of inspection. Water Containment: Proper containment and disposal of water and contaminants removed during the cleaning process are essential.</p><h3>Remotely Operated Vehicles</h3><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/2ytZ3qTp5hdwHHXBogaxS9/f159fe0a05f5d9192558ab2bdd1a900b/Deep-Trekker_family-hero.jpg" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">ROVs have revolutionized the cleaning of standpipe water tanks, especially for large or difficult-to-access tanks. These robotic vehicles are equipped with cameras and cleaning tools, allowing operators to remotely navigate and clean the tank's interior. ROVs are ideal for efficiently cleaning and inspecting tanks, ensuring thorough and consistent results without the need for human entry.<h3>Advantages:</h3><ul><li>Safety: ROVs eliminate the need for human entry into confined spaces, reducing the risk to workers.</li><li>Thorough Inspection: High-definition cameras provide detailed visuals of the tank's interior, aiding in identifying issues.</li><li>Efficiency: ROVs can access challenging areas and effectively remove contaminants. Reduces the time needed: quick deployment, does not need scheduling with divers.</li><li>Portable, compact, and battery powered allows for convenient transportation.</li><li>Allows for real time monitoring of the cleaning process and provides a detailed visual record and easy reporting.</li><li>Easy to sanitize and prevent contaminants from entering the water with a diver.</li><li>Cost-Effective: In the long run, ROVs can be cost-effective due to reduced labor and maintenance costs compared to manual or diver cleaning.</li></ul><h3>Challenges and Limitations:</h3><ul><li>Initial Cost: The setup cost for ROV equipment and training may be relatively high, especially for smaller organizations.</li><li>Limited Physical Manipulation: ROVs may have limitations in terms of the size and weight of objects they can manipulate.</li><li>Limited Reach: ROVs may have limitations in accessing extremely tight spaces or navigating complex tank designs.</li></ul></section><section><h2>Exploring Efficiency: A Standpipe Cleaning Case Study with Ron Perrin Water Technologies, Inc.</h2><p>In an exclusive conversation with Robert Perrin of Ron Perrin Water Technologies, Inc., we delved into the transformative impact of deploying the Deep Trekker VAC crawler, affectionately known as "Wallie," for standpipe cleaning projects. Wallie has proven to be an indispensable asset, particularly for standpipes exceeding 100 feet in height.</p><h3>Saving Resources and Time:</h3>Robert highlighted a significant shift in their cleaning approach, stating, "We use the vehicle instead of divers for tank cleaning." Previously, draining tanks for cleaning resulted in substantial water loss, up to 100,000 gallons. With the advent of the Deep Trekker VAC crawler, the Ron Perrin team now achieves efficient cleaning without taking the facility out of service, preserving valuable resources.<h3>Key Decision Factors:</h3>When opting for Deep Trekker, Robert emphasized pivotal factors in their decision-making process. Affordability played a crucial role, and the VAC crawler's lightweight design distinguished it from competitors, offering enhanced portability.<h3>Safety and Efficiency in Operations:</h3>Portability is paramount for the Ron Perrin team, especially when navigating complex standpipe environments. According to Robert, transporting the utility crawler over 110 feet in the air and submerging it into the water demands a safe and efficient solution—the Deep Trekker VAC crawler perfectly fits this requirement.<p>The decision to use the VAC crawler instead of human divers is rooted in safety and efficiency. Robert explained, "We often deal with at least 100 feet of water, so the divers can’t stay down as long as the Deep Trekker can." This choice not only enhances safety but also ensures cleaning tasks are completed promptly.</p><h3>Reliability and Durability:</h3>Expressing satisfaction, Robert noted, "Our crew likes the vehicle; they think it’s fun to use." He emphasized the reliability and durability of the VAC crawler, highlighting its consistent performance as a crucial aspect of their operations.<h3>Customer-Centric Experience:</h3>Robert praised Deep Trekker's commitment to customer needs, stating that the company has "always taken care of our needs." The emphasis on customer experience is evident in the reliability, support, and functionality of the Deep Trekker products.<h3>Conclusion:</h3>We extend our sincere thanks to Robert and Ron Perrin Water Technologies for sharing their story. For further updates, you can follow Ron Perrin Water Technologies on Facebook, LinkedIn, and explore their blog. The innovative use of Deep Trekker VAC crawler showcases the intersection of efficiency, safety, and reliability in standpipe water tank cleaning.<h2>Unlocking Efficiency with Deep Trekker VAC Crawler for Standpipe Cleaning</h2><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/bzTXVBzuZz90ZdsPMmi6o/1542ba5048af488075b6ebd0ab766464/deep_trekker_dt640_vac_vacuum_crawler_side-removebg-preview.png" alt="DESCRIPTION HERE" width="800" height="356" class="fr-fic fr-dii">In the realm of standpipe cleaning, the Deep Trekker VAC Crawler emerges as a purpose-built ROV, meticulously designed to navigate and thrive in challenging underwater environments. This section unveils the distinctive advantages that position the VAC Crawler as the ultimate solution for efficient, reliable, and cost-effective standpipe tank cleanings.<h3>Built for Versatility and Durability</h3><p>Deep Trekker ROVs are meticulously engineered for adaptability, rendering them essential instruments across various sectors and applications. Crafted from top-tier materials like stainless steel, precision-machined anodized aluminum, and fortified with carbon fiber shielding, they exhibit remarkable durability, readily withstanding the harshest of conditions.</p><h3>Time-Efficient Deployment and Advanced Features</h3><p>Experience swift deployment and operational efficiency with Deep Trekker ROVs. The VAC Crawler, powered by lithium-ion batteries, eliminates the need for a topside power source, enhancing portability. With advanced features like powerful LED lighting, real-time 4K video feed, 360-degree field of view, underwater imaging sonar, and seamless integration with sampling tools, it's equipped for comprehensive standpipe inspections and cleanings.</p><h3>Expert Guidance and Tailored Solutions</h3><p>Our team of seasoned industry experts are ready to offer their expertise and address any queries you may have regarding the incorporation of submersible robots into your projects. Whether your operations involve water tank inspections and cleaning, salvage operations, underwater inspections, search and recovery missions, aquaculture, environmental monitoring, or many other applications, we are at your service to help you understand how our ROVs can be tailored to meet your distinct needs.</p><h3>Secure Your Deep Trekker ROV Today</h3><p>The Deep Trekker VAC Crawler is not just an ROV; it's a transformative solution reshaping the landscape of standpipe cleaning. Elevate your approach to underwater inspections and cleanings with the efficiency, durability, and adaptability of Deep Trekker ROVs.&nbsp;<a href="https://www.deeptrekker.com/contact-us" target="_blank">Contact us</a> to receive a&nbsp;<a href="https://www.deeptrekker.com/request-quote" target="_blank">customized quote</a> tailored precisely to your project requirements. By incorporating Deep Trekker ROVs into your standpipe cleaning operations, you secure unparalleled safety, efficiency, and success in your underwater maintenance projects.</p></section>

Discover the ultimate standpipe water tank cleaning solution with ROVs. Redefine efficiency, adaptability, and speed for elevated underwater maintenance projects.

Revolutionizing Standpipe Water Tank Maintenance with ROVs

Image showing the screen of a Deep Trekker underwater ROV controller. The camera is looking at coral with fish in the background.

Explore the risks involved in commercial diving, and how ROVs contribute to safer operations by prioritizing diver well-being.

Enhancing Diver Safety: The Vital Role of ROVs in Commercial Diving

<section id="isPasted"><h2>Chapman Marine's Mission: Safeguarding Critical Infrastructure Below the Surface</h2><p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/6BEr6SgPsMMp32IVs2QRJB/5b94431418dd1547136c90fc4e0f152a/image4.jpg" alt="chapman dam" class="fr-fic fr-dii"></p><p>Chapman Marine specializes in underwater inspections of critical infrastructure such as dams, power plants, and raw water intakes. Their primary goal is to identify and address issues before they escalate, ensuring the safety and reliability of these structures. Prior to incorporating ROVs, the company primarily relied on dive teams to gather critical information about underwater conditions. Now, they bring their Deep Trekker DTG3 and PIVOT ROVs to every job.</p></section><section><h2>Enhancing Safety and Efficiency in Underwater Inspections: The Role of ROVs at Chapman Marine Inc.</h2><p>Chapman Marine Inc., one of Texas’ trusted commercial dive and underwater construction companies, has revolutionized the field of underwater inspections by incorporating Remotely Operated Vehicles (ROVs) into their routine operations. In this case study, we will explore how Chapman Marine utilizes ROVs to enhance safety and efficiency during pre-job, routine, and emergency inspections. By doing so, they have not only reduced costs but also improved the quality of deliverables and safety for their team and customers.</p></section><section><h2>The Challenge of Underwater Inspections</h2><p>Philip Wolfe, General Manager at Chapman Marine, highlighted a recurring challenge in their operations: "We get the information that there's a problem down there, we know we've got an issue, but we don't know what it is."</p><p>Often, their team receives limited information about underwater issues, making it difficult to assess risks accurately. This lack of clarity poses a significant safety hazard for divers. Ultimately, the ROVs are much faster, safer, and easier to deploy than a diver.</p></section><section><h2>The Solution: Leveraging ROVs for Comprehensive Underwater Inspections</h2><p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/2HlhtDflcr3ceNAxZXkicZ/8c6472960bb03f32ab1481c92057b8a9/image2.jpg" alt="Deep Trekker DTG3 ROV and tether reel package" class="fr-fic fr-dii"></p><p>Deep Trekker DTG3 ROV and tether reel package</p><h3>A Closer Look Before the Dive: ROVs Enhancing Safety in Pre-Job Inspections</h3><p>Before diving into the water, the team uses the limited information received from the customer to develop an initial understanding of the situation. This helps them gauge the safety risks involved.</p><p>“We use the ROVs to develop an understanding before we put divers in, to help us understand the safety risk before getting in the water,” Wolfe explains.</p><h3>Streamlining Routine Inspections: ROVs' Efficiency in Action</h3><p>ROVs are deployed for routine inspections, especially in confined spaces or areas requiring penetration. These inspections are completed in a fraction of the time it would take a dive crew, saving both time and resources.</p><p>“In some circumstances,” says Wolfe, “we use the ROV as the primary solution for certain inspections in areas where there's confined space or where we have to go into pipes or something like that, where it would take an entire day and a large crew to load out just to do the inspection, and we can do it in a few hours with the ROV and get the information that we need.”</p><h3>Responding Swiftly to Emergencies: ROVs in Critical Situations</h3><p>In emergency situations where immediate action is required, ROVs provide essential situational awareness. It’s dangerous to put divers into a situation where hazards aren’t entirely identified. Divers can be exposed to unknown dangers, making ROVs invaluable in understanding the situation better.</p><p>“We won't know all the safety issues. The ROVS help to develop the situation and we're often able to back off the urgency a little bit to say, ‘Here's the video. Here's what we understand. This is what we see is going on’. Then we pass that off to engineers, and make some recommendations so that they can develop that situation. So that's helpful for us and we're able to satisfy that gap in understanding in an emergency that often happens. It makes owners very uncomfortable, not knowing what's going on, and they want it fixed yesterday. So, it gives us some time to develop a better plan and then get out there and get after it.”</p><p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/2K5gmK7Ut4m7JK9qzINpgk/28dad4a5c6f8865d5f7246557bedf273/image1.jpg" alt="chapman case study dam" class="fr-fic fr-dii"></p></section><section><h2>ROVs vs. Tripod Mounted Sonar: A Paradigm Shift in Underwater Inspections</h2><p>Wolfe explained their preference for ROVs over a tripod mounted sonar (the current standard in the Gulf of Mexico for the oil industry that's used offshore when mapping and inspecting underwater assets), emphasizing the quick access ROVs offered to inspection sites. Tripod mounted sonar systems, while capable of producing high-quality images, required additional equipment and were less versatile.</p><p>“So, that was why we went with the ROV versus just a tripod mounted sonar, because of its very quick access to the site, where the tripod mounted sonar requires additional equipment to get there because it's not mounted to anything. It's a tripod, you need a boat and crew, you drop it down, and it sits on the bottom. You get a beautiful picture, but to get that beautiful picture, you have to have all that other stuff, and you have to have access to that point,” Wolfe illustrated.</p><p>“The limitations of a tripod mounted sonar is that it's not attached to an ROV, that it's not a two-man crew, and you have to have a boat. If you want GPS, you have to have that receiver attached to a boat. You have to do all this setup, which any GPS is going to require. I can't take a tripod mounted sonar with two guys and go 400 feet away from the shoreline when there's an issue on an intake or a dam or something. We need to have a place to launch, and all of these things that require additional equipment - which we have, but, It takes longer, it's more expensive, and a lot of times we just don't have direct access to the water - unless you're bringing ladders or you're doing a heck of a lot of work to get down there. If you're gonna do all that work, you might as well put a diver in the water.”</p></section><section><h2>ROVs in Action: Unveiling the Triad of Safety, Efficiency, and Quality</h2><p><img data-fr-image-pasted="true" src="https://images.ctfassets.net/kzewhs8e6cvu/740BJyCwuL4rDJcIdUIoo3/4c65a9c661ec75462cc06cfc9e703197/image3.jpg" alt="pelican case chapman " class="fr-fic fr-dii"></p><p>Chapman Marine has experienced numerous benefits since incorporating ROVs into their operations:</p><h3>Safeguarding Lives and Insights: How ROVs Prioritize Safety</h3><p>ROVs significantly reduce the risks associated with underwater inspections. Divers are no longer exposed to unidentified hazards, ensuring the overall safety of the team. “Anytime a diver enters without visibility, they are exposed to a risk that they don’t need to be if we run an ROV.”</p><h3>ROVs: The Turbocharged Engines of Inspection Efficiency</h3><p>Routine inspections that once took a full day to mobilize and deploy now require just a few hours with an ROV pilot, resulting in substantial time and cost savings.</p><h3>Delivering Clarity: ROVs and High-Quality Customer Communication</h3><p>ROVs provide high-quality video footage that can be shared directly with customers. This not only improves situational awareness but also allows customers to identify issues firsthand. “Visualization is the most important part of analysis,” explains Wolfe.</p><h3>Comprehensive Reporting: The Cornerstone of Effective Inspections</h3><p>After every inspection, whether performed by ROVs or divers, Chapman Marine produces comprehensive reports with videos, pictures, and descriptions of the work performed, and issues recommendations.</p><p>“When you're looking at the reports that we're putting together, what is good to decision makers, you're talking about the highest echelon of whatever organization that we're working for, and sending them a link to a video. They're not watching the video. They want a one to two page report that has a picture with a description. When you look at the executive level of making decisions on a project that we're working on, that's the type of report that we put together. It needs to be simple and very clear: ‘Here is what it looks like. Here's what your problem is.’ It is very helpful that the ROVs make producing reports very easy.”</p><h2>A New Era of Collaboration: ROVs Enhancing Customer Engagement</h2><p>Chapman Marine recognizes the importance of involving their customers throughout the inspection process. By utilizing ROVs, they can have their customer's eyes directly on live ROV surveys, aiding in issue identification. This customer-centric approach improves communication and helps solve problems more effectively. Previously, they had divers entering low visibility environments with regular cameras, or describing the situation for post inspection with hand drawings.</p><p>“The customer knows the original problem better than the divers. With an ROV video, we can have their eyes directly on the live ROV survey and can better identify issues rather than relying on diver descriptions. With ROVs we can get there fast, get the information, and get it in front of more eyes, quicker, to better solve the problem.”</p></section><section><h2>Deep Trekker: The Game-Changer in Underwater Inspections</h2><p><img data-fr-image-pasted="true" src="https://downloads.ctfassets.net/kzewhs8e6cvu/4H4NjDluiIL0HzoHj9U7RF/0aaf965ab8e7fe2b67793651ffd272ac/REV_Standalone.png" alt="REVOLUTION at Pier" class="fr-fic fr-dii"></p><p>transforming their approach to safety, efficiency, and customer satisfaction. ROVs have become indispensable tools that not only reduce costs but also enhance the quality of deliverables and the overall safety of their team. As Philip Wolfe succinctly puts it, "It's all about how to tell the customer what is happening," and ROVs have become their most valuable means of communication in the underwater inspection field.</p><p>When asked what he likes most about utilizing the Deep Trekker ROVs:</p><p>“Previous ROVs we have used required a lot of set up and programming that we just don’t have time for. With a Deep Trekker, I can plug it in and it’s ready to go, you do all the updates, and I can give it to somebody, give them some training, and then they can go out and execute.”</p><blockquote><p>It's not a science project every time we try to pass it off to somebody.</p></blockquote><p>So that's really what I'm looking for. I don't need a project. I've got enough projects. I just need something where I can take this and put it in the water now. I understand it takes work, there's a little bit of work, like building a report takes work, but there's different levels of work and there's a threshold at which I'm willing to go up to. But once it surpasses that threshold, it's just too much for us because it's too time consuming," explains Wolfe.</p><p>When asked why he stays with Deep Trekker:</p><p>“So, I will tell you, customer service for me is big. We're willing to pay a little bit more to have customer service because, in the end, that means saving time and money for us when we run into an issue - and that goes across everything that we do, whether we're buying a new engine for our boats, or whatever it is. We changed manufacturers for all the motors on our boats because there wasn't service for them. They're great motors, but no service doesn't help us. That's important, and I do like the updates. Deep Trekker just adds some additional capability to the ROV that you already have, to increase the functionality of the system. It’s awesome.”</p><h2>Exploring the Deep Trekker Family of ROVs</h2><p><img data-fr-image-pasted="true" src="https://downloads.ctfassets.net/kzewhs8e6cvu/5qr0cwf5B052kcAgyjmAH2/b3b3864cdf537fa3f718ccf8b045906e/Group_Glamor_Shot_2.png" alt="Family photo Group Glamor Shot 2" class="fr-fic fr-dii"></p><p>From left to right: DTG3, PHOTON, PIVOT, REVOLUTION</p><p>Deep Trekker ROVs present the ideal solution for conducting inspections of dams, infrastructure, and intake systems. Their compact and portable design makes them exceptionally well-suited for navigating confined spaces, ensuring versatility in your operations.</p><p>Equipped with long-lasting battery life and offering hybrid power options, Deep Trekker ROVs provide the endurance needed for extensive inspections. With a variety of tether options available, extending up to 500 meters, these ROVs offer flexibility in reaching various depths.</p><p>The intuitive BRIDGE controller enhances their capabilities and facilitates seamless integration with advanced modular add-ons, widening the spectrum of applications that can benefit from ROV inspections. The utility of Deep Trekker ROVs extends far beyond, encompassing a wide range of industries and inspection needs.</p></section><section><h3>DTG3</h3><p>The DTG3 tands as a versatile, cost-effective observation-class ROV, engineered for swift deployment and dependable underwater inspections, even at depths reaching 200 meters (656 feet). Its primary feature is a full HD panning camera boasting a comprehensive 270° view range, perfectly suited for thorough assessments, especially in confined areas.</p><p>The DTG3 offers a range of tether options, extending up to 500 meters (1,640 feet), thereby augmenting its versatility for a wide array of applications. Its durability is assured by a robust anodized machined aluminum body, meticulously designed to withstand the most challenging underwater conditions. Additionally, the DTG3 boasts adaptability through industry-specific modular enhancements, such as grabber claws and water samplers, making it an adaptable tool for various tasks.</p><h3>PHOTON</h3><p>The <a href="https://www.deeptrekker.com/products/underwater-rov/photon" target="_blank" rel="noopener">PHOTON</a> takes the concept of a portable "suitcase" ROV to a whole new level, weighing in at under 10 kg. Constructed from industrial-grade materials like carbon fiber and anodized aluminum, and featuring magnetically coupled drives, stainless steel components, and an acrylic lens cover, this micro ROV is built to withstand the harshest conditions, solidifying its reputation as the toughest micro ROV available.</p><p>Powered by Deep Trekker's BRIDGE technology, the PHOTON offers users a lightweight option with advanced inspection capabilities. Equipped with a rotating enhanced 4K camera and a six-thruster design for precise maneuverability, this ROV boasts the ability to expand its capabilities with additional tools and sensors, including sonar, DVL, and USBL. These features combine to make the PHOTON an ideal choice for any ROV inspection operation.</p><h3>PIVOT</h3><p>The <a href="https://www.deeptrekker.com/products/underwater-rov/pivot" target="_blank" rel="noopener">PIVOT</a> ROV offers users an unparalleled combination of stability, speed, and precise control, courtesy of its six robust thrusters. Designed for ultimate portability, this ROV is powered by lithium-ion batteries, ensuring you can take it anywhere your underwater exploration leads you.</p><p>Equipped with an enhanced 4K camera boasting a wide 220° field of view, the PIVOT provides exceptional visual coverage. With a depth rating of up to 305 meters (1000 feet) and super-bright LED floodlights, it ensures clear visibility even in challenging underwater environments.</p><p>The PIVOT is constructed to endure the rigors of underwater exploration, featuring a robust build comprising anodized machined aluminum, carbon fiber, and stainless steel components. BRIDGE technology empowers the PIVOT with enhanced capabilities and seamless integration with a variety of add-ons and sensors, including sonar, USBL, and DVL systems. The PIVOT stands as a testament to precision, durability, and versatility in underwater exploration.</p><h3>REVOLUTION</h3><p>The <a href="https://www.deeptrekker.com/products/underwater-rov/deep-trekker-revolution" target="_blank" rel="noopener">REVOLUTION</a> ROV emerges as the pinnacle of intuitive and stable underwater exploration, tailored for intricate missions beneath the waves. Unleash its potential with field-swappable lithium-ion batteries, providing extended portability to tackle even the most ambitious tasks.</p><p>With six powerful vectored thrusters at its disposal, the REVOLUTION offers unparalleled control and station holding capabilities, ensuring precise maneuvering in challenging underwater environments. Its advanced features include an enhanced 4K camera boasting an impressive 260° field of view, an exceptional 305-meter (1000-foot) depth rating, super-bright LED floodlights, and tether options stretching up to 500 meters (1,640 feet).</p><p>What truly sets the REVOLUTION apart is its integration with BRIDGE technology, enabling seamless incorporation of add-ons and sensors, such as sonar, USBL, and DVL systems. The REVOLUTION is your partner in achieving excellence in complex underwater missions, combining intuitive operation with cutting-edge capabilities.</p></section>

From pre-job assessments to emergency situations, see how ROVs outperform traditional methods.

Chapman Marine Inc. Case Study: Revolutionizing Underwater Inspections with ROVs

Image of unexploded ordnance (UXO) on sea floor.

Learn all about underwater mines and explosive ordnance disposal, the risks involved, and how ROVs can help while providing extra safety and speed for divers.

Everything You Need To Know About Underwater Mines

<p><span dir="ltr" id="isPasted"></span></p><p>Introducing SKYRON 2, the latest innovation in flying robotic inspection explicitly tailored for the non-destructive testing industry. Building upon SKYRON's visual and contact-based inspection tools, SKYRON 2 offers advanced capabilities for comprehensive assessments. Safety during flight operations is prioritized with SKYRON 2. A full product release on SKYRON 2 will happen later this May.</p><p><br></p><p></p>

The latest innovation in inspection flying robots explicitly tailored for the non-destructive testing (NDT) industry.

SKYRON 2 Release

Pipe crawler conducting an inspection inside a wind turbine blade.

Inspecting turbine blades is critical to plan maintenance and avoid downtime. Empower your team to conduct quick, safe, detailed inspections without contracting.

Performing Remote Visual Inspections of Wind Turbine Blades

<h1 id="isPasted"><br></h1><section><p>When you hear the word “drone,” you likely imagine an airborne device the size of a hat box that uses propellers to fly and is controlled remotely by someone in the immediate vicinity, perhaps in a park or another open area. Recreational drones like these have become increasingly popular in recent years.</p><p>But if you expand your definition of drones to include all unmanned aerial vehicles (UAVs), ranging from long-range drones used in military applications, to transport vehicles, to insect-sized drones, their potential applications expand exponentially. Imagine commercial airliners without pilots, drones capable of transporting shipping containers like those now delivered by trucks and ships, or even tiny, dexterous drones that fly into narrow gaps like insects.</p><p>While there are many obstacles for developers to overcome before these innovations can become a reality, the technology is evolving quickly – much faster than you might expect. This blog discusses where the technology currently stands and where it may go.</p><h2></h2><h3>High-Capacity Drones: Autonomy and Engine Innovations</h3><p>Scaling up drones to carry larger payloads, fly at higher altitudes, and travel greater distances presents major challenges for developers. Currently, semi- and fully autonomous large-scale drones (classified as UAVs that can carry a payload of greater than 1320 pounds and operate at altitudes greater than 18,000 feet) are most commonly implemented by military organizations to replace aircraft piloted by human operators.</p><p>Unlike smaller counterparts that rely on electric motors, larger drones use more robust internal combustion or jet engines. Not just a matter of size scaling, this means enhanced efficiency, reduced weight, and optimized fuel consumption, while also delivering precision control crucial in moving large loads.</p><p>By removing the human pilot and the various systems needed to support him, most large-scale drones are lighter and are usually built from lighter materials like plastics or carbon fibers. This increases the range of the vehicle. It can also reduce engine weight without compromising strength.</p><p>This is especially true for high-altitude long-endurance (HALE) drones. HALE drones must stay airborne for extended periods, sometimes days, at various altitudes and temperatures, and are often solar-powered. They are ideally suited for reconnaissance. In 2021, the U.S. Forest Service began testing HALE drones to locate and fight wildfires.</p><p>However, UAVs that operate at higher altitudes have more difficulty dissipating heat in the thinner atmosphere where they fly. <a href="https://www.macrofab.com/blog/overview-pcba-manufacturing-processes-technologies/" target="_blank">Printed circuit boards</a> for larger UAVs require additional heat transfer and use additional metal to connect to heat sinks to maximize performance at higher altitudes. This must be taken into consideration at the design stage. Simulating heat generation, flow, and dissipation in the development process is a valuable tool for these types of designs.</p><p>In terms of operational control, remotely piloted ICE (internal combustion engine) or jet aircraft aren’t significantly different from their traditional onboard piloted counterparts. A human operator guides the drone from a station with controls and monitors that are similar to the ones in airplane cockpits while cameras and radar-based imaging systems provide the visuals.</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1714573625993-1714573625993.png" alt="Drone carrying package" class="fr-fic fr-dii"><p>“Flying cars,” or “air taxis,” are already a reality, with China approving the first self-driving air taxi late in 2023. <a href="https://www.faa.gov/air-taxis" target="_blank">Similar air taxis are being planned in the USA</a>, though they will initially require a pilot on board for safety.</p><p>However, a significant hurdle in designing UAVs for human transportation or valuable cargo lies in bridging the information gap. While current sensors can track weather conditions, altitude, and airspeed, they cannot do so with the speed and sensitivity necessary. Onboard pilots can sense subtle changes in an aircraft’s behavior intuitively, a nuance challenging to replicate with sensors. By 2030, 6G wireless networks should significantly alleviate this issue by enabling ultra-low latency and improved data reliability, enhancing sensor responsiveness.</p><p>Lastly, many UAVs today boast semi-autonomous features like the ability to return to their starting point unaided. Autonomous or semi-autonomous flight software must be capable of dynamically adjusting flight paths in response to changing conditions, akin to how commercial airline pilots maneuver to avoid turbulence. This capability underscores the ongoing evolution and increasing sophistication of UAV technology in adapting to complex operational environments.</p><h2></h2><h3>Compact Drone Engineering: Revolutionizing Small-Scale UAVs</h3><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1714573626104-1714573626104.png" alt="Compact drone engineering" class="fr-fic fr-dii"><p>Every drone, from super large to shoe-box sized, relies on motors or engines to propel itself. In contrast to making drones larger, which requires increasing their power while reducing their overall weight, making them smaller necessitates removing motors altogether.</p><p>Using actuators to mimic how an insect flaps its wings plays a role in “micro drone” design. Early versions of this technology used ceramic materials to conduct and store electricity, but their inherent fragility made them unsuitable for repeated use.</p><p>The most recent innovations implement soft actuators composed of rubber cylinders surrounded by carbon nanotubes. Applying voltage causes the rubber cylinders to expand and contract repetitively and at high frequency (as much as 500 times per second), causing the drone “wings” to flap up and down.</p><p>These tiny drones, with their soft actuators, are resilient and capable of withstanding mid-air collisions, making them suitable for various tasks, including agricultural monitoring and pollination. Future uses may include structural inspection, search and rescue, surveillance, and data collection.</p><p><a href="https://www.macrofab.com/prototyping/" target="_blank">PCB designs</a> for smaller, more malleable devices have to consider factors like weight, rigidity, and resistance to impact and vibration. As in the case of larger UAVs, software simulation to test mechanical reliability in smaller UAVs is a valuable development tool.</p><h2></h2><h3>The Future of UAVs Great and Small</h3><p>In the future, UAV commercial passenger flights or large material transport using entirely autonomous flights still have some design challenges to overcome. Regulations, however, are more likely to hinder their long-term progress. Like self-driving cars, the adjustment period will require examining and discussing the risks and rationale of flying without a human pilot, with safety always taking precedence.</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1714573626041-1714573626041.png" alt="Uav future" class="fr-fic fr-dii"><p>On a smaller scale, however, UAVs may have more immediate practical applications. With micro drones with cameras that relay images back to a human operator, inspecting intricate mechanisms is possible in small spaces that are otherwise impossible to reach without dismantling the entire mechanism, such as industrial motors or airplane engines. Drones can even be used during natural disasters to locate missing or injured people who cannot be reached by rescue workers.</p><p>As UAVs shrink and grow, it will alter how we define them. Along with providing previously difficult-to-obtain images and delivering small payloads, UAVs will become a practical and labor-saving alternative to traditional means of transportation, cultivation, and commerce.</p></section><h3>Need UAV PCBAs Manufactured?</h3><p><a href="https://www.macrofab.com/pcba/" target="_blank" rel="noopener noreferrer">Check out MacroFab’s PCBA production services</a></p>

UAV technology continues to expand and become increasingly sophisticated.

The Future of UAV Design: Very Big and Very Small

<h1 id="isPasted">Wired for Autonomy: Confronting PCBA Complexities in Mobile Robotics</h1><section><p>The field of untethered robotics is booming, and across industries, autonomous robots are rapidly assuming responsibility for an increasing number of tasks. In their expansion into increasingly diverse industries, these robots place additional demands on their internal workings, specifically the PCBAs that help them function.</p><p>However, developing PCBAs for autonomous robot systems presents several unique challenges that electrical engineers must overcome to succeed. We take a deep dive into these challenges by exploring design considerations beyond those associated with conventional PCBAs.</p><h3>Beyond the Basics: Design Considerations for Autonomous Robots</h3><p>While core electrical principles remain a top priority, autonomous robotics introduces additional complexity to PCBA design that electrical engineers must consider from day one. To function properly, these machines must anticipate and plan for the unexpected in harsh, changing conditions.</p><p>Intuitive Machines’ Odysseus moon lander recently brought this to light, when the private spacecraft <a href="https://www.reuters.com/technology/space/moon-lander-described-alive-well-day-after-white-knuckle-lunar-touchdown-2024-02-23/" target="_blank">landed on the moon’s surface</a>. As much as the sideways landing attracted media attention, few reports focused on last-minute troubleshooting that kept the mission afloat, a testament to the quick-thinking nature of the engineers involved.</p><p>Here are some of the important factors to consider when designing PCBAs for untethered robotics:</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1713979758192-1713979758192.png" alt="Autonomous robot design considerations" class="fr-fic fr-dii"><ul><li><strong>PCBAs Must Prioritize Efficiency:</strong> Untethered robots almost entirely rely on batteries, so PCBAs must focus on efficiency. The key to this is meticulous component selection, such as using low-power microcontrollers and efficient voltage regulators, as well as excellent circuit design that minimizes standby currents. Using clock gating also maximizes battery life and reduces heat generation.</li><li><strong>Maintain Signal Integrity Amid Noise:</strong> Robots operate in dynamic environments with <a href="https://www.macrofab.com/blog/bypass-caps-decouple-your-way-to-cleaner-power/" target="_blank">potential electrical noise</a> from motors, sensors, and external sources. EMI can wreak havoc on robotic sensors, causing glitches, calibration issues, or even complete sensor failure. Consider layout strategies in detail to cut crosstalk and ground loops and maintain clear signal transmission.</li><li><strong>Build for Endurance:</strong> Many robots are subjected to extreme temperatures, temperature fluctuations, vibrations, and shocks. Use ruggedized PCBA boards that have components with adequate vibration and temperature ratings. To prevent overheating, soldering must be properly performed to handle thermal expansion and contraction, mechanical fatigue, and dust and moisture infiltration. Enclosures need to protect against dust and moisture egress.</li><li><strong>Size Matters:</strong> Robots must be mobile, so PCBAs must also be compact and lightweight to minimize robot weight. Choose wisely when choosing mechanisms within your robot, like vacuum track-based models or electromagnetic ones. They may increase the mass of your robot and reduce maneuverability. High-density interconnect (HDI) techniques and minimizing wasted space become crucial.</li><li><strong>Don’t Compromise Reliability:</strong> Autonomous robots, operating alone, demand ultra-reliable PCBAs to minimize failure. Filtering tackles this by reducing sensor noise for cleaner data, smoothing data for fewer errors, extracting key features for better navigation, and even lowering processing load for faster decision-making. Redundancy and fail-safe features further enhance reliability.</li><li><strong>Play by the Rules:</strong> Robots must comply with <a href="https://www.macrofab.com/blog/safeguarding-pcba-design-from-electromagnetic-interference/" target="_blank">Electromagnetic Compatibility (EMC) regulations</a> to ensure proper operation and avoid interfering with other electronic devices. Shielding techniques and filtering components become necessary.</li><li><strong>Ensure Maintainability:</strong> After assembling, it’s crucial to diagnose faults and perform maintenance. Make sure test points are conveniently accessible after the final assembly. Consider implementing Built-in Test (BIT) features on the PCBA for self-diagnostic features or options for wireless troubleshooting.</li></ul><h2><br></h2><h3>The Unexpected Factors: When Biology Interferes</h3><p>Biological influences are often overlooked when designing PCBAs for autonomous robotics but are an important factor. Autonomous robotics may work in many different environments, encountering biological challenges that can undermine even the most robust and reliable designs.</p><h3><p>Biofouling</p></h3><p>Biofouling, or the accumulation of microorganisms on surfaces, happens most frequently in aquatic environments. However, this issue can also occur within humid industrial settings or food processing facilities. Biofouling causes issues in many ways including:</p><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1713979758511-1713979758511.png" alt="Biofouling" class="fr-fic fr-dii"><ul><li><strong>Reduced Performance:</strong> Fouling on sensors, thrusters, and hulls can decrease efficiency and accuracy. As a result, sensors become less sensitive, propellers drag more, and overall power consumption increases. Special coatings applied to surfaces can deter organism attachment.</li><li><strong>Problems with Navigation:</strong> Fouling on navigational equipment leads to positioning and localization errors, which make it difficult for the robot to map its surroundings, keep its trajectory, and reach its destination.</li><li><strong>Maintenance Issues:</strong> Regular cleaning to remove biofouling is essential, particularly in remote locations. As a result, downtime occurs and reduces operational efficiency. Prevent biofouling with brushes or wipers, as well as scheduled cleaning protocols.</li><li><strong>Damage and Disruption:</strong> Biofouling can cause physical damage by promoting barnacle growth and corroding structures. Choosing materials that discourage organism growth is a passive defense, and monitoring systems can detect biofouling early and trigger automatic cleaning.</li></ul><p>Especially within industrial and food processing industries, biofouling can create a surprising but challenging issue for logistics robotics in order fulfillment, for example, or other autonomous vehicles. Make sure to consider this possibility when designing for specific applications.</p><h3><br></h3><h3>Biological Challenges Across Environments</h3><p>While biofouling dominates aquatic environments, other biological factors impact robots in other settings:</p><ul><li><strong>On Land:</strong> Dust, dirt, and debris can accumulate on sensors and cameras in terrestrial robots, hindering performance. Agricultural robots may encounter challenges with mud and plant debris.</li><li><strong>Airborne:</strong> Airborne robots face issues with dust, pollen, insects, and other airborne particles that can increase drag, reduce lift, and affect sensor accuracy.</li></ul><p>To address animal-related challenges, EEs can employ design strategies like:</p><p><strong>1. Physical Resilence:&nbsp;</strong></p><ul><li><strong>Challenge:</strong> Animals may chew on cables or antennas, causing malfunctions.</li><li><strong>Solution:</strong> Employ ruggedized components, reinforced substrates, and protective enclosures to enhance PCBA durability against physical damage from animal interactions. Additionally, utilize encapsulation and conformal coatings to safeguard critical components from moisture, dust, and possible damage by animals.</li></ul><p><strong>2. Sensor Integrity</strong>:</p><ul><li><strong>Challenge</strong>: Animals brushing against sensors can distort sensor inputs, leading to navigation errors.</li><li><strong>Solution:</strong> Design sensors with robust shielding, noise filtering capabilities, and redundancy features to ensure reliable operation and accurate data despite potential interference from animals. Develop strategies for preventing animals from brushing against sensors to keep distortions and navigational errors from happening. For example, anti-fouling paints or cages around the robot could prevent fouling, or sensors might be placed where animals cannot access them.</li></ul><p><strong>3. Mobility Optimization</strong>:</p><ul><li><strong>Challenge:</strong> Animals blocking pathways or obstructing movement can impede the robot’s forward progress.</li><li><strong>Solution:</strong> Develop strategies to address mobility constraints caused by animals blocking pathways or obstructing movement, ensuring that robots can navigate effectively and complete their objectives. This could include low-power LEDs or subtle sounds that encourage animals to move away. Optimize power management systems to maximize operational autonomy and extend battery life in resource-constrained environments where robots may interact with animals.</li></ul><h3>Security: The Next Level in AMR PCBA Design</h3><img src="https://s3-us-west-1.amazonaws.com/wevolver-project-images/froala%2F1713979758575-1713979758575.png" alt="AMR PCBA security" class="fr-fic fr-dii"><p>AMR PCBA security</p><p>PCB design traditionally focuses on protecting against electrical malfunctions and physical damage. However, for AMRs (autonomous mobile robots) connected to the internet, cybersecurity emerges as a key concern. Hacking hazards present significant security risks. A compromised robot can open the door to major security breaches. Thus, incorporating encryption and secure boot mechanisms in PCBA design is essential to block unauthorized access.</p><p>Hardware Trojan Horses also pose a silent yet profound threat. These sneaky modifications, made during manufacturing, can go almost unnoticed. To counteract this, it’s critical to partner with trustworthy suppliers and employ hardware authentication methods.</p><p>Consider working with a partner with a connected technology platform that keeps you in touch with your manufacturing process from start to finish. Moreover, work with a partner that employs robust security practices and can provide proof of such, such as ISO and ITAR certifications, or membership in the ERAI, an organization established to <a href="https://www.macrofab.com/blog/electronics-industry-counterfeit-parts-problem/" target="_blank">combat counterfeit electronics</a> and high-risk components in the electronics industry. MacroFab holds these standards, and it is a member of ERAI.</p><p>Another challenge is the theft of PCBAs after robot deployment, especially those containing valuable intellectual property. Consider using tamper-evident seals or protective enclosures if you will be installing robotics in an unsupervised area.</p><p><strong>Want to read more about designing PCBAs for robotics? Read <a href="https://www.macrofab.com/documents/reshaping-robotics-how-pcba-advances-drive-tomorrows-autonomous-solutions/" target="_blank">Reshaping Robotics: How PCBA Advances Drive Tomorrow's Autonomous Soutions</a> now.</strong></p><h2><br></h2><h3>Conclusion: Embracing the Challenge</h3><p>The realm of PCBA design for autonomous robots transcends the traditional electrical engineer’s domain. While electrical fundamentals remain the cornerstone, navigating the complexities of this field necessitates venturing beyond the confines of the schematic. It’s a world where understanding environmental stresses, mitigating biological influences, and safeguarding against security vulnerabilities are equally critical.</p><p>By embracing these unique challenges and fostering a spirit of relentless innovation, electrical engineers will become the architects of a new era in robotics. The future holds immense potential for these autonomous machines, with robust, adaptable PCBAs serving as their foundation.</p><p><strong>Need PCBAs for your robotics project?&nbsp;</strong></p></section><p><a href="https://factory.macrofab.com/quick_quote?mbsy_source=c2dfbfd3-8c8b-4098-87b7-c7e0e06119ec&campaignid=62990&mbsy=6DBV3m" target="_blank">GET AN INSTANT QUOTE NOW</a></p><section><h5><br></h5></section><p><br></p>

Autonomous robotics must anticipate and plan for the unexpected, often in harsh, changing environments. We take a deep dive into these challenges by exploring design considerations beyond those associated with conventional PCBAs.

Wired for Autonomy: Confronting PCBA Complexities in Mobile Robotics

<p dir="ltr" id="isPasted">Microtunneling is a trenchless construction method using a remotely controlled, steerable tunnel-boring machine for underground pipeline installation. It minimizes surface disruption, making it ideal for urban and sensitive areas. This technique ensures precise pipeline alignment and involves simultaneous excavation and pipe installation, enhancing safety and efficiency. Widely used for utilities, microtunneling's precision and reduced environmental impact make it a preferred choice for constructing water, sewage, and other infrastructure systems in congested settings.</p><p dir="ltr">This article highlights the progress a young engineering student team from Switzerland has made with its self-developed micro tunnel boring machine. It describes the project on its way to revolutionizing the tunneling industry with specific regard to its innovative 3D-printing-like tunneling mechanism.</p><h2 dir="ltr">The Journey of Swissloop Tunneling</h2><p dir="ltr"><a href="https://swisslooptunneling.ch/" target="_blank">Swissloop Tunneling</a> is a student group from ETH Zurich that focuses on developing innovative tunneling technologies. This team, composed of students, works on designing and testing tunnel boring machines that incorporate advanced technologies and methods. Their efforts aim to enhance the efficiency and reduce the costs of tunneling processes, contributing to the broader goal of revolutionizing tunneling to facilitate ambitious infrastructure projects, including proposed systems like the Hyperloop transportation system.</p><p dir="ltr"><em><strong>Further reading:&nbsp;</strong></em><a href="https://www.wevolver.com/article/swissloop-tunneling-revolutionizing-the-tunneling-industry" target="_blank"><strong><em>Swissloop Tunneling: Revolutionizing the Tunneling Industry</em></strong></a></p><p dir="ltr">Throughout the last 3 years, over 100 Swissloop Tunneling members have made contributions to a common goal: unleashing the potential of time-, cost-, and resource-efficient tunneling. In this regard, innovation is needed to accelerate the infrastructural progress to benefit society by supporting the rapid expansion of connected underground systems. Therefore, Swissloop Tunneling aims to contribute to advancements in technology, demonstrated by its two iterations of prototypical tunnel boring machines since its founding in 2020.&nbsp;</p><p dir="ltr">Building upon its first model named Groundhog Alpha, the team has maintained the first machine components’ strengths while further extending it with technological add-ons, designing certain subsystems from scratch, conducting tests, and optimizing for higher reliability. Those efforts have now led to the current model Groundhog Beta.</p><h2 dir="ltr">The Groundhog Beta</h2><p dir="ltr">The current model of the association’s (micro) tunnel boring machine named Groundhog Beta consists, among others, of these functions:</p><h2 dir="ltr">Erosion</h2><p dir="ltr">Extracts and processes the underground material during the boring phase. At the front of the machine, where the cutterhead is placed, a special soil-conditioning foam is used to help decompose the sticky clay ground in Bastrop (TX), where the prototype was being tested. The erosion subsystem can further handle small to medium-sized rocks by crushing them into smaller pieces. A suctioning mechanism then transports the eroded material through and out of the machine. At this point, an external sedimentation system is ensuring a constant circulation of used water and the removal of the extracted material.</p><p dir="ltr"><span class="fr-img-caption fr-fic fr-dib" style="width: 790px;"><grammarly-extension data-grammarly-shadow-root="true" style="position: absolute; top: 0px; left: 0px; pointer-events: none;" class="dnXmp"></grammarly-extension><grammarly-extension data-grammarly-shadow-root="true" style="position: absolute; top: 0px; left: 0px; pointer-events: none;" class="dnXmp"></grammarly-extension><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzEzNzExOTM0NDY1LXguanBnIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" style="width: 100%px;" class="fr-fic fr-dib" alt="groundhog-beta-soil-conditioning-foam"><span class="fr-inner" spellcheck="false">Fig. 1: Groundhog Beta tackling clay using soil conditioning foam</span></span></span></p><h2 dir="ltr">Navigation</h2><p dir="ltr">Consists of a two-component system. The steering component allows for angled digging and enables withholding stronger vibrations. It consists of a comprehensive sensory system to achieve an accurate autonomous movement of the machine. The propulsion component gets the machine moving forward by coordinated gripper plates that push the machine forward through the tunnel wall.</p><p dir="ltr"><span class="fr-img-caption fr-fic fr-dib" style="width: 790px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzEzNzEyMDA4NjA4LURTQzA1MDk5ICgxKS5qcGciLCJlZGl0cyI6eyJyZXNpemUiOnsid2lkdGgiOjk1MCwiZml0IjoiY292ZXIifX19" style="width: 100%px;" class="fr-fic fr-dib" alt="groundhog-beta-hydraulic-powered-propulsion"><span class="fr-inner" spellcheck="false">Fig. 2: Swissloop Tunneling's hydraulics-powered propulsion component</span></span></span></p><h2 dir="ltr">Starting platform</h2><p dir="ltr">Placed in the launching area or on the surface, the starting platform enables the machine to launch from various angles.</p><h2 dir="ltr">Tunnel liner</h2><p dir="ltr">One of the most innovative aspects of Groundhog Beta is its tunnel lining mechanism. The liner mechanism simultaneously builds the interior tunnel wall while continuously moving forward with the tunnel boring machine, acting like a 3D printer. As it stands right now, a mechanism of this type has not been tested in tunneling yet and provides an ecologically sustainable solution regarding the reusability of the wall material. By using a pneumatic system, a polypropylene granulate to later build the tunnel wall gets transported into the machine. It then gets extruded by melting it and steering the viscous material into the right shape, finally being cooled down to achieve its intended tunnel wall structure. This mechanism has been optimized since last year - especially in terms of reliability. Additionally, an external testing system was designed to make isolated testing of this subsystem’s functionality possible. In the end, a 15mm thick tunnel wall is produced, being able to withhold the intense forces of machine and earth pressure.</p><p dir="ltr"><span class="fr-img-caption fr-fic fr-dib" style="width: 790px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzEzNzExOTc1MDE2LURTQzA2NDY1LmpwZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 100%px;" class="fr-fic fr-dib" alt="groundhog-beta-tunnel-lining"><span class="fr-inner" spellcheck="false">Fig. 3: Polymer starting to come out of the tunnel lining component on the right</span></span></span></p><h2 dir="ltr">Achievements Over the Years</h2><p dir="ltr">In addition to refining the engineering processes, the Swissloop Tunneling team has consistently participated in every Not-a-Boring Competition an event aimed at fostering innovation in tunneling technologies. Not-a-Boring Competition is organized each year in the USA by The Boring Company, founded by Elon Musk.</p><p dir="ltr"><span contenteditable="false" draggable="true" class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable"><iframe width="640" height="360" src="https://www.youtube.com/embed/OJ0tIHHXuS4??si=AofBJ4PDGhPfTxmg&amp;wmode=opaque&amp;rel=0&amp;enablejsapi=1&amp;origin=https://www.wevolver.com" frameborder="0" allowfullscreen="" class="fr-draggable" data-lf-form-tracking-inspected-kn9eq4roawkarlvp="true" data-lf-yt-playback-inspected-kn9eq4roawkarlvp="true" data-lf-vimeo-playback-inspected-kn9eq4roawkarlvp="true"><span class="fr-mk" style="display: none;">&nbsp;</span></iframe></span></p><p dir="ltr"><span contenteditable="false" draggable="true" class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable"><iframe width="640" height="360" src="https://www.youtube.com/embed/osnFHy8KeYI?&amp;ab_channel=SwissloopTunneling&amp;wmode=opaque&amp;rel=0&amp;enablejsapi=1&amp;origin=https://www.wevolver.com" frameborder="0" allowfullscreen="" class="fr-draggable" data-lf-form-tracking-inspected-kn9eq4roawkarlvp="true" data-lf-yt-playback-inspected-kn9eq4roawkarlvp="true" data-lf-vimeo-playback-inspected-kn9eq4roawkarlvp="true"></iframe></span><br>The team has exhibited its excellence by winning awards for innovation and design at the first two competitions, held in Las Vegas (NV) in 2021 and Bastrop (TX) in 2023. Ahead of the 2024 competition in Bastrop, the team dedicated significant efforts to optimizing their machine and making key adaptations. These efforts paid off spectacularly at the Not-a-Boring Competition 2024, where Swissloop Tunneling triumphed by winning 1st Place Overall and the Champion Award.</p><p dir="ltr"><span class="fr-img-caption fr-fic fr-dib" style="width: 790px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNzEzNzEyMDY1NjgyLURTQzA2MDg4LmpwZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 100%px;" class="fr-fic fr-dib" alt="swissloop-tunneling-team-picture"><span class="fr-inner" spellcheck="false">Fig. 4: The Swissloop Tunneling Team</span></span></span></p><p dir="ltr">With these achievements, the team remains committed to pushing the boundaries of innovation. Swissloop Tunneling will continue to enhance and refine its machinery, further developing its capabilities to fully realize the remarkable potential of advanced tunneling technology.</p><h2 dir="ltr">Conclusion</h2><p dir="ltr">The advancements in tunneling technology showcased by the recent developments of the micro tunnel boring machines are reshaping the landscape of construction and infrastructure. By integrating innovative 3D-printing-like methods for tunnel lining, these machines are setting new benchmarks for efficiency, cost-effectiveness, and environmental sustainability in tunnel construction.&nbsp;</p><p dir="ltr">Such technological breakthroughs promise to revolutionize urban development and the future of transportation, making the once-distant dreams of projects like the Hyperloop increasingly attainable.</p>

Innovative micro tunnel boring technologies are revolutionizing underground construction, setting new standards in efficiency and sustainability, and paving the way for future transformative infrastructure projects like the Hyperloop.

Transforming Underground Construction with Swissloop Tunneling

In this episode, we discuss research coming out of George Mason University where the RobotiXX lab has been training robots to drive more like humans

Podcast: Robot That Drives Better Than The Average American
