<p>FullControl GCode Designer is new open-source and free software for the unconstrained design of additive manufacturing print paths and related aspects of the manufacturing plan.</p><p><strong>Challenge</strong></p><p>The conventional workflow for additive manufacturing is to develop a CAD model, convert it to triangulated STL surface geometry, slice that model into layers, identify the print path for each layer, and output a manufacturing file (GCode). Each stage introduces errors and limitations.</p><p><strong>Solution</strong></p><p>In contrast, FullControl GCode Designer (www.fullcontrolgcode.com) turns this whole process on its head. Rather than creating a CAD model and then determining how to move a print head around to simply fill the required 3D volume, FullControl GCode Designer allows the precise print path to be designed directly. This provides unparalleled design freedom and epitomizes the concept of Design for Additive Manufacturing. It allows the designer to think “What can I produce by moving a nozzle with a controlled extrusion rate?” which can allow dramatically different structures to those seen conventionally.</p><p><span class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable" contenteditable="false" draggable="true"><iframe src="https://www.youtube.com/embed/KlxuZ5JnA0k?&amp;wmode=opaque&amp;rel=0" frameborder="0" allowfullscreen="" class="fr-draggable" style="width: 789px; height: 441px;"></iframe></span></p><p><strong>Results</strong></p><p>FullControl allows unlimited exploration of 3D space for printing and of the potential capabilities of 3D printers. It’s been used to print single extrusions 10x wider than the nozzle diameter and other extrusions 10x narrower than the nozzle diameter. That means a 100-fold difference in design resolution of fully dense extrusions is possible from a single system, which is entirely incomparable with conventional additive manufacturing print paths. It’s an example of how FullControl GCode Designer encourages innovative thinking beyond the general design rules, which are actually based on principles of printing with slicer software rather than the true capabilities of 3D printing hardware. Similarly, creating structures with innovative texture and porosity is possible when explicitly designing the 3D movement of the nozzle whilst extruding.</p><table style="width: 100%;"><tbody><tr><td style="width: 50.0000%;"><div class="fr-img-space-wrap"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgyNjAwOTc0LVN0cmluZyBleGFtcGxlLnBuZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 300px;" class="fr-fic fr-dib"><span class="fr-inner" spellcheck="false">String Example 10x Narrower</span></span></span><p class="fr-img-space-wrap2">&nbsp;</p></div></td><td style="width: 50.0000%;"><div class="fr-img-space-wrap"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgyNjIzOTA0LTEweCB3aWR0aCBleGFtcGxlLmpwZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 300px;" class="fr-fic fr-dib" alt="10x Width Example String Structure"><span class="fr-inner" spellcheck="false">10x Width Example String Structure</span></span></span><p class="fr-img-space-wrap2">&nbsp;</p></div></td></tr><tr><td style="width: 50.0000%;"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgyODE3MjQzLVJhbWVuIGV4YW1wbGUuanBnIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" style="width: 300px;" class="fr-fic fr-dib"><span class="fr-inner" spellcheck="false">Noodle-Like Structure Example</span></span></span><br></td><td style="width: 50.0000%;"><br><div class="fr-img-space-wrap"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgyOTQwNTg1LVJpcHBsZSB0ZXh0dXJlIGV4YW1wbGUuanBnIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" style="width: 300px;" class="fr-fic fr-dib"><span class="fr-inner" spellcheck="false">Ripple-Like Texture</span></span></span><p class="fr-img-space-wrap2">&nbsp;</p></div></td></tr></tbody></table><p><span class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable" contenteditable="false" draggable="true"><iframe src="https://www.youtube.com/embed/Sj3Nqtjfw0Q?&amp;wmode=opaque&amp;rel=0" frameborder="0" allowfullscreen="" class="fr-draggable" style="width: 789px; height: 598px;"></iframe></span></p><p>FullControl GCode Designer is applicable for a wide range of designs and applications. It’s been used to print highly controlled simple structures for material characterization as well as complex mathematical forms, in-situ process monitoring, hybrid manufacturing, and production runs &gt;1000. The benefits apply to structures designed and printed at the microscale, such as medical stents, to those at the other end of the spectrum such as large-format polymer and concrete 3D printing. Materials printed with FullControl include thermopolymers, ceramics, silicone, conductive metal inks, biological cell-laden hydrogels, fibre-reinforce polymers and many more materials. Wherever a print path is used, FullControl GCode Designer is relevant because the benefits translate across material systems and size scales.</p><p><br></p><div class="fr-img-space-wrap"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgyOTkxNjEwLVN0ZW50IGV4YW1wbGUuanBnIiwiZWRpdHMiOnsicmVzaXplIjp7IndpZHRoIjo5NTAsImZpdCI6ImNvdmVyIn19fQ==" style="width: 300px;" class="fr-fic fr-dib"><span class="fr-inner" spellcheck="false">Stent Example</span></span></span><p class="fr-img-space-wrap2"><span class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable" contenteditable="false" draggable="true"><iframe src="https://www.youtube.com/embed/lWHxT3HQ4Wo?&amp;wmode=opaque&amp;rel=0" frameborder="0" allowfullscreen="" class="fr-draggable" style="width: 789px; height: 465px;"></iframe></span>&nbsp;</p></div><p><strong>Major Benefits of the FullControl GCode Designer are</strong></p><table border="1" cellpadding="0" cellspacing="0" width="584"></table><ul><li><strong>Quality</strong> - the ability to optimize all aspects of the printing procedure to maximize quality, reliability and speed, and overcome any challenges associated with a specific material, printing system or part design.</li><li>Design file<strong>&nbsp;efficiency</strong> - the design file for the sinusoidal shoe sole concept in the image below requires about 1KB of data, whilst also allowing full parametric adjustment of the size and shape, whereas an STL file (nonparametric) of a similar model may require 1000000 times more data.</li><li>3D print paths and <strong>previously impossible structures</strong> – the stent in the image above was printed with continuous vertical extrusion (see the video below)</li><li><strong>Hybrid manufacturing</strong> and <strong>multi-tool processes</strong> – FullControl facilitates the use of multiple tools and auxiliary equipment. Explicit design of tool movement paths eliminates the challenges of tool-part collisions during hybrid manufacturing and allows advanced manufacturing activities such as in-situ process monitoring.</li><li>The software is <strong>entirely free</strong> and requires <strong>no installation</strong>. It’s integrated into Excel, which is used as an extremely powerful user interface (enabling Excel’s broad functions to be used in design parameters). No CAD software or software licences are required.</li></ul><p><br></p><div class="fr-img-space-wrap"><span class="fr-img-caption fr-fic fr-dib" style="width: 300px;"><span class="fr-img-wrap"><img src="https://images.wevolver.com/eyJidWNrZXQiOiJ3ZXZvbHZlci1wcm9qZWN0LWltYWdlcyIsImtleSI6ImZyb2FsYS8xNjIwOTgzMDUxNTQ5LVNob2Vzb2xlLmpwZyIsImVkaXRzIjp7InJlc2l6ZSI6eyJ3aWR0aCI6OTUwLCJmaXQiOiJjb3ZlciJ9fX0=" style="width: 300px;" class="fr-fic fr-dib"><span class="fr-inner" spellcheck="false">Sinusoidal Shoe Sole Example</span></span></span><p class="fr-img-space-wrap2">&nbsp;</p></div><p><span class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable" contenteditable="false" draggable="true"><iframe src="https://www.youtube.com/embed/e68Vc69yAo8?&amp;wmode=opaque&amp;rel=0" frameborder="0" allowfullscreen="" class="fr-draggable" style="width: 789px; height: 469px;"></iframe></span><br></p><p>For a detailed demonstration of the design workflow, see the technical introduction video (20 mins)&nbsp;</p><p><span class="fr-video fr-deletable fr-fvc fr-dvb fr-draggable fr-active" contenteditable="false" draggable="true"><iframe src="https://www.youtube.com/embed/yGtyw3oLOVQ?&amp;wmode=opaque&amp;rel=0" frameborder="0" allowfullscreen="" class="fr-draggable" style="width: 791px; height: 437px;"></iframe></span></p><p>More information and other tutorials are available at <a href="//www.fullcontrolgcode.com" rel="noopener noreferrer" target="_blank">www.fullcontrolgcode.com</a></p><hr><p>CREATE Education would like to thank Andrew Gleadall for taking the time to share his work in research focusing on biomedical polymers and additive manufacturing at Loughborough University.</p><p>To learn more about additive manufacturing solutions and how CREATE Education can help and support your University research visit <a href="https://www.createeducation.com/" rel="noopener noreferrer" target="_blank">www.createeeducation.com</a> or speak to our specialists at <a href="mailto:enquries@createeducation.com" rel="noopener noreferrer noopener noreferrer" target="_blank">enquries@createeducation.com</a>.</p>

Ripple texture printed using the a simple print-path design, using a parametric FullControl design file.

Andy Gleadall, Lecturer at Loughborough University develops FullControl GCode Designer in the hope to empower people to do the impossible with scripts and slicers.

Open-Source Software for Unconstrained Design in Additive Manufacturing
