| Product Specification

STMicroelectronics AEK-POW-LDOV02J Evaluation Board

Evaluation board based on L99VR02J automotive linear voltage regulator and designed with configurable output voltage.

Specifications

ProductEvaluation Board
TypeLDO Voltage Regulator
For Evaluation OfL99VR02J
Output Current500 mA
Operating Supply Voltage0.8 to 5
Operating Temperature-40 to 175 °C
ApplicationsSensors, Microcontroller Supplies, Automotive Display Drivers, Infotainment Processors

Overview

The board includes an enable pin, reset, watchdog, advanced thermal warning with output overvoltage detection, and fast output discharge. It operates from -40°C to 175°C and is suitable for electronic applications with high-temperature environments. The board provides various features, including selectable output voltages, a wide operating temperature range, and various protection features. The AEK-POW-LDOV02J Evaluation Board is a tool that helps engineers design and test linear voltage regulators for use in automotive applications. Typical applications include microcontroller supplies, automotive display drivers, sensors, and infotainment processors.

AEK-POW-LDOV02J Evaluation Board Features

The STMicroelectronics AEK-POW-LDOV02J evaluation board is a valuable tool for evaluating the L99VR02J automotive linear voltage regulator. The L99VR02J is a high-performance, high-temperature linear voltage regulator that is the core component of the evaluation board. The board can be configured to output any of eight fixed voltages from 0.8V to 5V. This makes it useful for a wide range of applications requiring a specific output voltage.

The evaluation board has different protection and diagnostics functionalities.  These include enable pin, reset, watchdog, programmable short circuit output current (Ishort), advanced thermal warning with output overvoltage detection, and fast output discharge. The output voltage of the board can be selected using the jumpers on the board.

The watchdog can be configured to reset the board if the output voltage goes out of range or is unused for a specified period. This helps to prevent the board from becoming unstable or damaged. The enable pin is used to turn off the board when it is not being used. This helps to save power and extend the life of the board. The reset pin can restart the board if it becomes unstable. This can be useful for troubleshooting problems with the board.

The evaluation board includes other components, such as a power supply, a load, and an oscilloscope. These components are used to test and evaluate the performance of the L99VR02J automotive linear voltage regulator. The board can operate in temperatures ranging from -40°C to 175°C. This makes it ideal for applications subject to extreme temperatures, such as automotive and industrial applications.

Getting Started with AEK-POW-LDOV02J Evaluation Board

Here are the steps on how to use the evaluation board:

1. Connect the board to a power supply using any power source.

2. Select the output voltage using the jumpers on the board. The available output voltages are 0.8V, 1.2V, 1.5V, 1.8V, 2.5V, 2.8V, 3.3V, and 5V.

3. Connect the load that can be any device requiring a regulated power supply.

4. Monitor the output voltage using the oscilloscope or multimeter.

5. Test the board by connecting it to a variety of loads and verifying that the output voltage is stable and within the specified range.

Applications


The STMicroelectronics AEK-POW-LDOV02J evaluation board is a platform for various applications, such as microcontroller supplies, automotive display drivers, and sensors. These include infotainment processors, power supplies for LED lighting, medical devices, and test and measurement equipment. The board's adjustable output voltage and high-temperature operation make it suitable for a variety of applications, particularly those in harsh environments.
