Evo

EVO is a compact folding unit. Equipped on the front EVO offers a camera on a 3-axis stabilize gimbal that records video at 4k resolution up to 60 frames per second and a recording speed up to 100mbps in an H.264 or H.265 codec. Using real-glass optics EVO captures photos at 12 megapixels with a wide dynamic range for more details and color. An integrated computer vision systems provides forward obstacle avoidance, rear obstacle detection and bottom sensors for more accurate landings and stable indoor flights. EVO boasts flight times up to 30 minutes with a range of 7KM.

Specifications

Weight 863 g
Flight time30 m
Camera4 k
60 frames per second
Max. Yaw Rate200 dps
Max. Inclination Angle35 °
Max. Ascent/Descent SpeedAscent: 5 m/s
Descent: 3 m/s
Max. Horizontal Speed20 m/s
Diagonal Wheelbase338 mm
Propeller Size8.3 x 2.9 "
Video Link Frequency2.4 ~2.4835 GHz
Receiver Frequency2.4 ~2.4835 GHz
Flight ModesGPS · ATTI · SPORT
Operating Environment Temperature0° C ~ 40 ° C
Camera
Still Photography ModesSingle shot
Burst shooting
Auto Exposure Bracketing (AEB) Time-lapse
Video Recording ModesNormal · Picture In Video (PIV)
Max Frame Rates4K60, 2.7K60, 1080p120, 720p240
Max Field of View94 °
Supported SD Card TypesMicro-SD, 4 GB - 128 GB, Class 10 or UHS-3
Aircraft Battery
Battery TypeRechargeable Lithium-Polymer Battery
Capacity4300 mAh
Battery Voltage Charging11.4 V

Overview

Using real-glass optics EVO captures photos at 12 megapixels with a wide dynamic range for more details and color. An integrated computer vision systems provides forward obstacle avoidance, rear obstacle detection and bottom sensors for more accurate landings and stable indoor flights.  EVO boasts flight times up to 30 minutes with a range of 7KM.

EVO offers failsafe features letting you know when the battery is low and it’s time to return to home.

The system includes a remote controller which houses a 3.3-inch OLED screen providing you with flight information or a live 720p HD video feed letting you see the camera view without the need for a mobile device.

The Autel Explorer app is available for Apple iOS or Android devices and connects to the remote controller and gains access to more advanced settings and autonomous flight features like Dynamic Track, Viewpoint, Orbit, VR first person view and Waypoint mission planning.

References

Contains a large collection of video's shot with the Evo drone, as well as Evo product video's.

https://www.youtube.com

Describes the product, the remote control, and shows accessories.

https://auteldrones.com
