What Are Proportional Pneumatic Valves?

You can use these specialised devices to obtain precise and dynamic control of air/gas pressure and flow; that’s why proportional pressure control valves and proportional flow control valves are the most common types used in pneumatic applications.

How Does A Proportional Pneumatic Valve Work?

Proportional pneumatic valves can regulate airflow or pressure to a fine degree of accuracy. Where simpler types of valves are either just open or closed, proportional valves respond to an electrical or mechanical control signal to achieve continuous adjustment. The electrical control signal is usually in the form of a 0-10 voltage or a 4-20mA current loop. As the input signal varies within these ranges, the valve changes its position proportionally to deliver an even, gentle modulation of air pressure or flow.

Proportional pneumatic valves vary the position of their mechanical elements, such as poppets or spools, in response to an analogue input signal. This is usually provided by a motor-driven mechanism, or more commonly a solenoid. In turn, the spool or poppet movement alters the size of the opening or valve port to increase or decrease the passage of compressed air. Think of it as turning on a tap: not a lever type that can open or close it all the way in one move, but with a knob that you turn gently to moderate the flow.

Proportional solenoid control valves use a restrictor or throttling to alter the dimensions of the port opening in order to manage the flow rate of gas or fluid. Doing this influences a pneumatic or hydraulic system’s key process parameters, including pressure, temperature and fluid levels. This restrictor is governed by a signal received from a controlling actuator, in this case the solenoid. Solenoid control allows for high-precision positioning of the valve, and you can also add integral sensors to create a closed-loop system. Sensors collect information on the valve position so that they can provide feedback on the resulting airflow or pressure. This is then used to adjust the valve position continuously in real-time.

Proportional Pneumatic Valve Types

There are two main types of proportional pneumatic valves, which can also be combined in one unit:

Proportional Pressure Control Valves

These maintain the system at a precise pressure level by dynamically counteracting fluctuations in air pressure. The valve controls the amount of air released through the ports and is a critical feature in applications like process control in manufacturing that demand consistent pressure.

Proportional Flow Control Valves

Regulating the flow rate is integral to other operations like maintaining air pressure. The control signal adjusts the size of the port opening in direct proportion to preset parameters or feedback in a closed-loop system. This enables the valve to deliver precise flow rates, which is critical for many industrial applications.

Solenoid Proportional Pneumatic Valves

In a direct-operated two-way solenoid valve, there are only two switching states: on or off. Standard proportional solenoid valves offer a continuous range of valve positions, with a plunger acting as a throttle or restrictor. This plunger is usually controlled proportionally using variable DC input voltage, although due to the problems arising from static friction, this signal is typically converted by special control electronics into a signal with pulse width modulation (PWM).

PWM is a common technique for controlling input current and voltage to electrical devices. By rapidly turning the power on and off, the plunger is made to oscillate in a balanced state that controls its sliding friction. Applying power opens or closes the valve, allowing proportional control of the airflow. The total amount of power supplied to the solenoid varies according to its duty cycle or the amount of time the power is on or off, usually expressed as a percentage. Longer off time – a low duty cycle – means low power, while full power is expressed as a 100% duty cycle.

A 50% duty cycle sets the solenoid to the middle of its operating range, but it can vary continuously according to the proportional requirements of the application. If you need accurate, precision control, you’ll have to select and configure your solenoid control valves in relation to their particular purpose. This will usually depend on your application’s pressure range, including maximum operating pressure and the valve’s operating voltage and kV value. Other factors include response time, power consumption and port connections.

Why Choose Proportional Pneumatic Valves?

You’ll discover several key advantages to the continuous modulation offered by proportional pneumatic valves:

Precision

Proportional pneumatic valves enable high-precision adjustments with smooth transitions, thereby minimising the chance of exceeding set parameters and experiencing pressure surges.

Efficiency And Durability

The gradual and smooth transitions of proportional pneumatic valves mean the system will suffer less wear and tear, prolonging its life. Avoiding constant on/off power changes and surges means this type of valve also uses less energy.

Versatility

Solenoid proportional control valves can be used in several ways in a pneumatic system, both for direct flow control, pressure control or both, including control of vacuum pressure. You can fine-tune them to suit many different applications, including automotive, process control and automation, medical and robotics. Ensuring that your equipment functions optimally at the precise air pressure it requires will improve product quality and reduce unnecessary downtime. The seamless modulation of pneumatic actuators in delicate applications offers the utmost precision in movement and operation.

Proportional Pneumatic Valves Offer The Best Performance

Proportional pneumatic control valves are the best choice for any application where you need precision, delicacy or extreme accuracy. When you integrate proportional control valves into your pneumatic systems, they’ll become critical components in a sophisticated automation network. They’ll align with other controllers, such as PLCs, receiving and responding to sensor readings, and ensuring that all elements of your system are functioning optimally and within required parameters. As technical specs continue to improve, costs are going down, so that they’re being adopted by an ever-expanding range of industries.
